Advanced XRF Portable Gold Testers Precisous Metal Testers
Instrument introduction
EDX-Pocket 3 is a handheld energy dispersive X-ray spectrometer specially developed for field and on-site analysis with the characteristics of small volume, light weight and handheld. The serial models are such as hazardous substance analyzer, alloy grade analyzer, soil analyzer, precious metal analyzer, minerals analyzer.
It can be widely used in fields such as minerals analysis, geographic analysis, scrap metals recycling analysis and archeology research. Samples are including all natural minerals, slag, rocks, soils slurry ranging from sulfur to uranium; they have solid, liquid and powder forms.
EDX-P series are the instruments really realizing on-site analyzer fully condensing wisdom and painstaking effort of Napco people after years of preparation and development. EDX-P is of high quality, high configurations and outstanding characteristics. It brings you brand-new visual impact by its streamlined line,exhibits unique charm by its magnificent colors, displays beauty of science and technology by its exquisite kernel, safeguards itself well by its reliable protection devices and shows humanity concern by its mallness and handiness.
Performance characteristics
Same performance and reliability as the bench-top spectrometers due to combined use of low-power integrated
mini X-ray tube and large area Be-window electric-cooling Si-Pin detector with the former having low power
consumption but high excitation efficiency.
The instrument is small, light and portable, providing on-site and in-situ analysis whenever and whatever. High resolution (640*480)PDA, coupled with mini multi-channel analyzer in Bluetooth communication, keepsthe measurement data in hands under any circumstances. Adapt to rapid analysis in handheld mode or long time precise test in stand mode.The instrument is proof against water and dust and operable in high temperature and high humidity surroundings. Besides, the design of the protective case consists with that of the military supplies: moisture,
shock and pressure proof.
Professional software specifically designed for tests of alloy elements characterized by high sensitivity, short measurement time, simple operation and low requirements of operators. Rapid identification of alloy categories, auto qualitative and quantitative analysis of multi elements, different test options, free and unlimited adding of test modes and in-built intensity correction mode correcting deviation caused by different geometric shapes or uneven structural density. One battery’s operating time of 4 hours and three batteries in supply guarantees us the test in any time and at any place. Solar or car charger is optional.
Technical specifications
Model EDX-Pocket 3 handheld energy dispersive mineral analyzer
Detector 13mm 1 electro-cooling Si-PIN detector
Excitation source mini 40kV/50μA X-ray tube, Ag anode end window
Detection time 10-200 S (handheld or seat)
Forms: Solid, liquid, powder
Measurable range S-U
26 elements can be tested simultaneously
Detection limit 0.001%~0.01%
Correction Ag
Safety Administrator model with in-built password, no operators can use it without authorization
Data usage Edited inside PDA, and stored in PC for saving and printing. Massive storage card is supplied
Power Operating time of two fully-charged Lithium batteries is no less than 8 hours
Weight 1.35KG
Ambient temperature -20°C-+50°C
Ambient humidity not less than 85%
Standard configurations
PDA/Si-PIN semi-conductor detector/ Amplifier circuit/ x-ray tube and high and low voltage power PDA mineral sample analysis software/ lab test stand (optional) Super-capacity SD memory card, SD card reader/ shock, pressure & water-proof, suitcase with lock
Application fields
Mineral exploration and survey
In-situ inspection of rocks, soil, sediments and ores
