Volumetric Micro Transfer Pipette

DW-EP Adjustable Non-Autoclavable pipette

DW-EP Adjustable Non-Autoclavable pipette is ISO 2001 and ISO14001 certified. All models feature a continuously adjustable smooth micrometer rather than a click-stop micrometer. The easy-to-use locking wheel at the top of the handle ensures accuracy and precision during use. All pipettes are calibrated at the factory, and the calibration certificate is included with each. Both single and multichannel lines are available.

DW-EP Adjustable Pipette:
Easy digital volume setting.
Easy and convenient single hand locking lever.
Eight sizes to cover a wide volume range. ( 0.1μL - 10mL )
PTFE ( Fluorine resin ) is used in the airtight chamber of the instrument, so the instrument keeps its air tightness and precise reproducibility for long hours.
Filtered Nozzles are used for volume models larger than 1000μL.
Tip ejector allows tip ejections without touching the tip.
Tip ejector is made of plastic to avoid damaging glass tubes.

Cat. No	Volume Setting	Volume range(μL)	Increments(μL)	Usable tips
EP-2	Digital Setting	0.1~2	0.002	Biopure 10
EP-10		0.5~10	0.01	Biopure 10
EP-20		2~20	0.02	biopure 200
EP-50		5~50	0.05	biopure 200
EP-100		10~100	0.1	Biopure 200
EP-200		20~200	0.2	Biopure 200
EP-1000		100~1000	1	Biopure 1000
EP-5000		1000~5000	10	Biopure 5000
EP-10ML		1000~10000	10	Biopure 10000



Cat. No	Volume(μL)	Accuracy(%)	Precision(%)
EP-2	0.2	±12.0*	≤6.0*
	1	±5.0	≤2.5
	2	±3.0	≤1.0
EP-10	1	±4.0	≤3.0
	5	±1.0	≤1.0
	10	±1.0	≤0.5
EP-20	2	±5.0	≤3.0
	10	±1.0	≤1.0
	20	±1.0	≤0.4
EP-100	10	±2.0	≤1.0
	50	±1.0	≤0.3
	100	±0.8	≤0.3
EP-200	20	±1.0	≤0.5
	100	±0.8	≤0.3
	200	±0.8	≤0.2
EP-1000	100	±1.0	≤0.5
	500	±0.8	≤0.3
	1000	±0.7	≤0.2
EP-5000	1000	±1.0	≤0.3
	2500	±0.8	≤0.3
	5000	±0.6	≤0.2
EP-10ML	1000	±2.0	≤0.4
	5000	±0.8	≤0.3
	10000	±0.4	≤0.2
