Help CenterLab Oil Melting/melt Point Tester With 8 Operator Account
Related Products
-
Laboratory Equipment of Touch Screen Control Oil Melting/melt Point TesterUS$ 1,000 - 15,000MOQ: 1 Piece -
Automatic Melting Point Apparatus China Drawell TesterUS$ 920 - 2,999MOQ: 1 Piece
-
DRAWELL Laboratory Melting Point Apparatus/Melting Point Tester PriceUS$ 1,100 - 16,000MOQ: 1 Piece
-
JH40 Automatic Melting Point MeterUS$ 1,000 - 2,000MOQ: 1 Piece
-
JHY30 Automatic Melting Point MeterUS$ 1,500 - 2,400MOQ: 1 Piece
Oil melting point instrument series>>>
Automatic oil automatic precise measuring instrument of melting various oil product melting point, good navigation automatic grease instrument of melting the perfect combination of high precision Peltier temperature control technology and high-definition video camera technology, not only provides the test result is accurate,stable and reliable for users,but also bring the test experience efficient and convenient for users. Peltier temperature control technology can realize the high precision temperature control,high-definition video can be conveniently and clearly see the whole process of sample melting, automatic detection to eliminate the subjective error to determine the melting point ,reducing the labor intensity of the staff, convenient for the user to accurately measure the melting point of the sample.
The main technical indicators
Model | JHY30 | JHY50 |
Temperature control range | RT-100℃ | 6-100℃ |
Detection method | Semi-automatic | Semi-automatic |
Capacity per batch | 2pc./batch | 2pc./batch |
Temperature resolution | 0.1℃ | 0.1℃ |
Temperature gradients | (0.1-10.0)℃/Min | (0.1-10.0)℃/Min |
Temperature accuracy | ±0.3℃ | ±0.3℃ |
Repeatability | 0.1℃/Min±0.1℃ | 0.1℃/Min±0.1℃ |
Camera&Video | Camera | Camera&Video |
Video playback | — | YES |
Operator account | — | 8 |
Result storage | 200 | 400 |
SD card capacity | 8G | 8G |
Display | TFT Touch screen | TFT Touch screen |
Interface | USB RS232 SD card Enternet | USB RS232 SD card Enternet |
Opening capillary size | I.D>1.0mm,O.D.1.4mm Double opening | I.D>1.0mm,O.D.1.4mm Double opening |
Power | 110-220V 50/60HZ 120W | 110-220V 50/60HZ 120W |
The main technical parameters
1:Paltier precise temperature function;
2:a key automatic detection function;
3:in line with the international and ISO in the determination of the melting point of oils and fats.
The main technical parameters
Model | JHY70 | JHY90 |
Temperature control range | RT-100℃ | 4-100° |
Detection method | Fully automatic(compatible with Semi-automatic) | Fully automatic(compatible with Semi-automatic) |
Capacity per batch | 2pc./batch | 2pc./batch |
Temperature resolution | 0.1℃ | 0.1℃ |
Temperature gradients | (0.1-10.0)℃/Min | (0.1-10.0)℃/Min |
Temperature accuracy | ±0.3℃ | ±0.3℃ |
Repeatability | 0.1℃/Min±0.1℃ | 0.1℃/Min±0.1℃ |
Camera&Video | Camera | Camera&Video |
Video playback | NO | YES |
Operator account | 10 | 20 |
Result storage | 600 | 1000 |
SD card capacity | 8G | 16G |
Display | TFT Touch screen | TFT Touch screen |
Interface | USB RS232 SD card Enternet | USB RS232 SD card Enternet |
Opening capillary size | I.D.1.0mm,O.D.1.4mm | I.D.1.0mm,O.D.1.4mm |
Power | 110-220V 50/60HZ 120W | 110-220V 50/60HZ 120W |
Standard:SNT0801.5-2015,GB/T24892-2010,GBT12766-2008
