Help CenterSM57HT76-2804A Nema 23 Bipolar Stepper Motor 18.9kg.cm
Related Products
-
SM42HT38-1684 HB Stepper Motor CE and RoHs Holding Torque 3.6kg.cmUS$ 4 - 10MOQ: 2 Pieces -
42BYGH Series High Torque Nema 17 Stepping MotorUS$ 4 - 10MOQ: 2 Pieces
-
85BYGH450C-01 4 Phase Nema 34 Step Motor, Low Current 2A, High Torque 63kg.cmUS$ 12 - 50MOQ: 5 Pieces
-
85BYGH450A-06 2 Phase Nema 34 Stepping Motor With Pully on ShaftUS$ 18 - 35MOQ: 5 Pieces
-
57BYGH Series Nema 23 Stepping MotorUS$ 7 - 15MOQ: 2 Pieces
1.8° Nema 23, Size 57mm High Torque Hybrid Stepping Motor
Technique Parameter:
Itam | Specifications |
Step Angle | 1.8° |
Step Angle Accuracy | ±5% (full step, no load) |
Resistance Accuracy | ±10% |
Inductance Accuracy | ±20% |
Temperature Rise | 80°C Max.(rated current,2 phase on) |
Ambient Temperature | -20°C~+50°C |
Insulation Resistance | 100MΩMin. ,500VDC |
Dielectric Strength | 500VAC for one minute |
Shaft Radial Play | 0.02Max. (450 g-load) |
Shaft Axial Play | 0.08Max. (450 g-load) |
Max. radial force | 75N (20mm from the flange) |
Max. axial force | 15N |
Model No. | Rated | Current | Resistance | Inductance | Holding | # of Leads | Rotor | Weight | Detent | Length | |
Single Shaft | Double Shaft | V | A | Ω | mH | kg-cm |
| g-cm2 | kg | kg-cm | mm |
SM57HT76-1006A | SM57HT76-1006B | 8.6 | 1 | 8.6 | 14 | 13.5 | 6 | 480 | 1 | 0.68 | 76 |
SM57HT76-2006A | SM57HT76-2006B | 4.5 | 2 | 2.25 | 3.6 | 13.5 | 6 | ||||
SM57HT76-3006A | SM57HT76-3006B | 3 | 3 | 1 | 1.6 | 13.5 | 6 | ||||
SM57HT76-2804A | SM57HT76-2804B | 3.2 | 2.8 | 1.13 | 3.6 | 18.9 | 4 | ||||
