63ZYT01D 12v 24v 40v dc motor 4000rpm 20kgcm 85w
USD $8 - $20
/ Piece
5 Pieces(Min.Order)
- 100000 Piece / Pieces per Month
- SHANGHAI
- T/T Credit Card
You May Like
-
O.D 63mm 12v dc motor 3000rpm, 24v dc motor 3000rpm, rated power 50w 75w 100w 150w
-
OD 63mm hight torque 24v brush dc motor with encode
-
63ZYT02B 12v 24v DC electric motor rated 0.35Nm 4000rpm 150w IE1
-
O.D63mm Permanent Magnet 12v, 24v, 40v Electric Dc Motor, rated 50w, 100w, 150w, 200w, 250w
-
80ZYT03A High Torque High Power 24V 12V DC Electric Motor 1Nm 3000rpm 315w
-
63ZYT02C high speed high torque dc electric motor rated 7000rpm 0.4Nm 300w
Product Details
| Brand Name: | SmartAutomation | Place of Origin: | China | Model Number: | 63ZYT01D |
| Type: | Micro Motor | Certification: | CE, ROHS | Torque: | 0.2N.m |
| Usage: | Car, Electric Bicycle, Fan, Home Appliance | Construction: | Permanent Magnet | Efficiency: | IE 1 |
| Protect Feature: | Drip-proof | Voltage(V): | 12, 24, 36, 40v | Output Power: | 85w |
| Continuous Current(A): | customed | Speed(RPM): | 4000rpm | Commutation: | Brush |
Product Description
Motor technical parameter
Shaft HRC 36~40 ; NMB ball bearing
Hard ferrit magnet, 2- poles
Protection class IP 50
Insulation class: F, operating temperature range:-40°C~+140°C
CE and ROHS certified
Model | 63ZYT01D | |||
Rated voltage | V dc | 12 | 24 | 40 |
Continuous rated speed | rpm | 4000 | 4000 | 4000 |
Continuous rated torque | mN.m | 200 | 200 | 200 |
Continuous current | A | 10 | 5 | 3 |
Starting torque | mN.m | 1534 | 1534 | 1534 |
Starting current | A | 57.5 | 30.3 | 18.2 |
No load speed | rpm | 4500 | 4500 | 4500 |
No load current | A | 1.8 | 1.0 | 0.6 |
Demagnetization current | A | 120 | 60 | 36 |
Rotor inertia | Gcm2 | 400 | 400 | 400 |
Motor length | Mm | 95 | 95 | 95 |
Weight of motor | g | 1000 | 1000 | 1000 |
