chinese factory High quality Double battery isolation protection controller for car
USD $3.5 - $4
/ Piece
1 Piece(Min.Order)
- 10000 Piece / Pieces per Month
- Shanghai
- T/T Credit Card
You May Like
-
chinese factory high quality circular hydraulic oil tank
-
chinese factory high quality Push pull negative pressure fan for airport farm Central air-conditioning
-
chinese factory high quality High pressure fan for airport farm Central air-conditioning
-
chinese factory high quality Mobile six leaf fan for Factory workshop outdoor bar
-
chinese factory high quality Permanent magnet frequency conversion aerator for Fish pond
-
12V 500W Hydraulic Permanent Magnet DC Motor
Product Details
| Brand Name | JINLE | Place of Origin | China | |
| Model Number | isolation | Rated Voltage | 12V/24V |
Product Description
Type | Double battery isolation protection controller |
Voltage | 12VDC/24VDC |
Current | 120A |
Peak current | 200A |
Automatic connection voltage | 13.3V-14.5V/26.6V-29V |
Isolation protection voltage | 12.8V/25.6V |
Overcharge protection voltage | 16V/32V |
Main functions:
1. Isolation: under normal circumstances, cut off the connection between the main battery and the auxiliary battery to ensure that there is no internal friction between the two batteries and extend the service life of the battery.
2. Protection: when starting, the positive and secondary batteries are automatically connected to ensure sufficient current to start the vehicle, effectively reducing the starting voltage of the vehicle
If the main battery is insufficient, the vehicle can also be started.
3. Control: automatically detect voltage and implement protection function. After starting, when the voltage of the secondary battery is insufficient, charge and maintain it.
4. Additional intelligent power borrowing function
When it is necessary to use high-power electrical appliances, press the "emergency button" to connect the main and auxiliary batteries in the manual mode and borrow electricity from the auxiliary batteries.
Connection Description:
Connect the two thick lines of the isolator to the positive pole of the main battery and the secondary battery respectively
according to the wiring diagram. The black wire is connected to the negative pole of the main battery, and the blue emergency
start wire is connected to 86. The isolator is working properly.
according to the wiring diagram. The black wire is connected to the negative pole of the main battery, and the blue emergency
start wire is connected to 86. The isolator is working properly.
1. Business Type
a. Manufacturer located in Wuxi City, Jiangsu Province
b. Factory cover an area of 6000 square meterselectric forklift motor
c. Employees: over 70 in office & workshops
2. Certificates
CE, ISO9001 etc
3. How long could we get the goods?
a. 10-20days for mass production based on your quantity
b. 5~10days for Sampe orders
4. Quality Control
a. 100% inspection before packing electric forklift motor
b. Spot inspection before shipment
a. Manufacturer located in Wuxi City, Jiangsu Province
b. Factory cover an area of 6000 square meterselectric forklift motor
c. Employees: over 70 in office & workshops
2. Certificates
CE, ISO9001 etc
3. How long could we get the goods?
a. 10-20days for mass production based on your quantity
b. 5~10days for Sampe orders
4. Quality Control
a. 100% inspection before packing electric forklift motor
b. Spot inspection before shipment
