JLY-D3.2A4E81/TBTBO1 China Manufacturer Popular Sale Power Unit for Dock Leveler

JLY-D3.2A4E81/TBTBO1 China manufacturer

popular sale power unit for dock leveler

General Description:

The hydraulic power unit consists of gear pump,motor, hydraulic valves,tank and multi-function manifold.The application of the normally open solenoid valve not only enables the ramp to float with the truck,but also offers an emergency stop function for safety consideration.The submersion of the motor and pump in the oil ensures the low noise level and lifetime of the power unit.

SPECIAL NOTES:

1.The AC motor is of S3 duty cycle,which can only work intermittently and repeatedly, i.e., 1 minute on and 9 minutes off.
2.Clean all the hydraulic components concerned before installation of the power unit.
3.Viscosity of the oil should be 15～68 CST and the oil should be clean and free of impurities,N46 hydraulic oil is recommended.
4.Check the oil level in the tank after the initial running of the power unit.
5.Oil changing is required after the initial 100 operation hours,afterwards once every 3000 hours.

REMARK:

1.Please feel free to contact me  consult for the different pump displacement, motor power or tank capacity.
2.The manual override function is available on request.
