380V 1.5KW/ 2KW 1440rpm Hydraulic Power Unit/Hydraulic Power Pack for Tyre Changer

GENERAL DESCRIPTION:

This power unit is equiped with a high pressure gear pump, a AC motor, a multi-functional manifold valves and a tan, etc. Specially designed for tyre changer, support the operation of three sets double action cylinders.

OUTLINE DIMENSION & HYDRAULIC CIRCUIT OPTIONAL :

SPECIAL NOTES:

1.Clean all the hydraulic parts concemed before mounting the power unit.

2. Viscosity of the hydraulic oil should be 15-68 cst,which should also be clean and free of impurities. N46 hydraulicoil is recom-mended.

3.This power units should be mounted horizontal.

4.Check the oil level in the tank after the first start of the power unit.

5.Oil changing is required after the initial 100 operation hours afterwards once every 3000 hours.

APPLICATION:

           DC POWER UNITS                         AC POWER UNITS

 From row material to product, we concerate on each details:

1.Sample service: samples can provide preferential.

2.customized services: a variety of power units can be customized according to customer demand.

3. aftermarket service: according to consumer requirements, technical guidance on the use and other aspects. In case of quality problems under normal use, free replacement within one year of free maintenance for life.
