Mini 12v24v 48v DC AC 220V 110v 380v Hydraulic Power Packs/power Unit for Car Lift

 mini 12v24v 48v DC AC 220V 110v 380v hydraulic power packs/power unit for car lift

GENERAL DESCRIPTION:

This POWER UNITS FOR ELECTRIC WORK PLATFORM is equiped with a high pressure gear pump, a AC motor, a multi-funtional manifold values and a tank,etc. Specially designed for two-poles car lift ,with the function of power lift and gravity lowering.The lowering speed can be controlled by manual adjustable flow valve.

OUTLINE DIMENSION & HYDRAULIC CIRCUIT OPTIONAL :

SPECIAL NOTES:

1. The power unit is of S3 duty ,which can only be worked  intermittently,ie.,1minute on and 9 minute off.

2.Clean all the hydraulic parts concemed before mounting the power unit.

3. Viscosity of the hydraulic oil should be 15-68 cst,which should also be clean and free of impurities. N46 hydraulicoil is recom-mended.

4.This power units should be mounted horizontal.

5.Check the oil level in the tank after the first start of the power unit.

6.Oil changing is required after the initial 100 operation hours afterwards once every 3000 hours.

APPLICATION:

Packing Details  :  We pay high attention to the hydraulic dc motor 12v 2200w 2800rpm torque dc motor motor packaging, adopt poly foam packing and then pack them to plywood case to protect dc motor, this series of complete packing enable you receive good products.

Delivery Details :  15 days after order

1.Sample service: samples can provide preferential.

2.customized services: a variety of power units can be customized according to customer demand.

3. aftermarket service: according to consumer requirements, technical guidance on the use and other aspects. In case of quality problems under normal use, free replacement within one year of free maintenance for life.

Our factory was established in 1996, professional in hydraulic dc motors, hydraulic power pack units, hydraulic cylinders, solenoid valves etc. They are widely used for forklift, vehicle tailboard, lift table, electric stacker, wing plate and other hydraulic equipment etc.

We have nearly 20 years' manufacturing experience with a strong team of 30 engineers for research and development. The motors' annual output has been more than 200,000 sets.

So far, we are the only designated OEM hydraulic power unit motor supplier in China for US WAI Company, OEM forklift motor supplier for Korea SOOSUNG. Also, we cooperated Korea KOPACK, Turkey Hidros and HELI in China.

We have been attentively persisting in manufacturing hydraulic dc motors for 20 years.

Below is the information about Jinle Factory transactions conducted via . If you require further details regarding the transaction data, please click on the below picture.

ENTERPRISE HONOR:

Our factory will attend PTC ASIA 2017 in shanghai , our booth No.E3, G3-2 ,welcome to our booth!
We also attend the Canton fair and Hannover messe ,pls feel free to contact us if you are interested in our products, we will bring to the booth ~

Q: Do you accept OEM manufacturing?

A: Yes! We do accept OEM manufacturing. You could give us your samples or drawings.

Q: Can we design our own package or print our own logo?

A: Yes! You could! Package will be acording to your requirements?

Q: Could we get samples?

A: Yes! Definitly! The samples will be sent to you preferentially.

 Q: How much time about the mass production?

 A: The lead time of mass production will depend on quantity, production and so on.

 Q: Could I customize our products in your factory?

 A: Customization is available. You can send me your specifications and drawings.

  SOLENOILD SWITCH                                 12v/24v POWER UNITS FOR CAR LIFT

XQD-3C 24V 4.0KW DC MOTOR                      12V 0.8KW PM DC MOTOR
