800W Permanent Magnet 24V DC Motor Brush
| Type | Voltage | Power | Speed | Rotation | O.D. | Torque | Duty | Weight |
| MB08XXN | 24V | 0.8KW | 3000RPM | BI-DIRECTIONAL | 80mm | 2N.m | S3 | 2.5kg |
| MA08XXN | 12V | 0.8KW | 3200RPM | BI-DIRECTIONAL | 80mm | 2N.m | S3 | 2.5kg |
Insulation Class: F
Protection Class: IP54
Features of 800W Permanent Magnet 24V DC Motor Brush:
100% copper wire
stable running, high efficiency, low noise
good service after sale
12V, 24V, 48V, 60V etc. on your request
Customized production is available!
Supply for OEM Production!
nearly 20 years' manufacturing experience
According to the different requirements of customers, our DC motors have been broadly used in the fork-lift, container van tail-board, van door system, jumping car, snow-sweeper, etc.
Motor’ type can be divided into 12V,24V voltage system.
Unload |
Speed |
5091 RPM |
Current |
10.230 A |
|
Max_Torque |
Torque |
2.670 N.m |
Current |
64.340 A |
|
Speed |
3639 RPM |
|
Efficiency |
66.35% |
|
Output Power |
1017.40 W |
|
Max_Efficiency |
Efficient |
69.36% |
Speed |
4016 RPM |
|
Torque |
1.770 N.m |
|
Current |
44.200 A |
|
Output Power |
744.30 W |
|
Max_Pout |
Efficiency |
66.35% |
Speed |
3639 RPM |
|
Torque |
2.670 N.m |
|
Current |
64.340 A |
|
Output Power |
1017.40 W |
Q: Do you accept OEM manufacturing?
A: Yes! We do accept OEM manufacturing. You could give us your samples or drawings.
Q: Can we design our own package or print our own logo?
A: Yes! You could! Package will be acording to your requirements?
Q: Could we get the samples?
A: Yes! Definitly! The samples will be sent to you.
