Nine Teeth Forklift Electric 24V DC Motors 2.2KW
- Shanghai
- T/T Credit Card
You May Like
-
Electric High Torque 12V DC Motor Winch 1.7KW
-
Electric DC Motor 1.5kw 12 Volts CW/CCW For Hydraulic Power Pack
-
Electric DC Motor 1.5kw 12 Volts CW/CCW For Hydraulic Power Pack
-
24V / 12V / 48V / 60V DC Electrical Motor For Forklift 1.5KW / 2.2KW / 3.0KW
-
Hydraulic 1 HP Permanent Motor dc 12 Volt
-
500W 24V Small Electric DC Motor for Scooters
Product Details
| Brand Name | JINLE | Place of Origin | Jiangsu, China | |
| Model Number | ZD2420 | |||
| Certification | CE | Torque | 6N.m | |
| Usage | Boat, Car, Electric Bicycle, Fan, Home Appliance | Construction | Series Wound | |
| Efficiency | IE 4 | Protect Feature | Drip-proof | |
| Continuous Current(A) | Current | Speed(RPM) | 2700RPM | |
| Commutation | Brush |
Product Description
Nine Teeth Forklift Electric 24V DC Motors 2.2KW
Features for Nine Teeth Forklift Electric 24V DC Motors 2.2KW :
100% copper wire
stable running, high efficiency, low noise
good service after sale
12V, 24V, 48V, 60V etc. on your request
Customized production is available!
Supply for OEM Production!
nearly 20 years' manufacturing experience
Specification of Nine Teeth Forklift Electric 24V DC Motors 2.2KW :
| Type | ZD2402 |
| Voltage | 24V |
| Power | 2.2KW |
| Speed | 2700RPM |
| Rotation | CW |
| O.D. | 114mm |
| Operating Mode | S3 |
| Insulation Class | F |
| Protection Degree | IP54 |
| Weight | 7.5kg |
| Torque | 6N.m |
Curve for Nine Teeth Forklift Electric 24V DC Motors 2.2KW :
Parameter for Nine Teeth Forklift Electric 24V DC Motors 2.2KW :
| Unload | |
| Speed | 5570RPM |
| Current | 28.41A |
| Max_Torque | |
| Torque | 6.06N.m |
| Current | 109.36A |
| Speed | 2753RPM |
| Efficiency | 67.12% |
| Power Out | 1747.2W |
| Max_Efficiency | |
| Efficiency | 67.25% |
| Speed | 2914RPM |
| Torque | 5.16N.m |
| Current | 98.26A |
| Power Out | 1575.7W |
| Max_Power Out | |
| Efficiency | 67.12% |
| Speed | 2753RPM |
| Torque | 6.06N.m |
| Current | 109.36A |
| Power Out | 1747.2W |
Welcome to inquire about Nine Teeth Forklift Electric 24V DC Motors 2.2KW .
Hot Products:
1,sample service: samples can be provided.
2,customized services: a variety of motors can be customized according to customer demand.
3, aftermarket service: according to consumer requirements, technical guidance on the use and other aspects. In case of quality problems under normal use, free replacement within one year of free maintenance for life.
Q: Do you accept OEM manufacturing?
A: Yes! We do accept OEM manufacturing. You could give us your samples or drawings.
Q: Can we design our own package or print our own logo?
A: Yes! You could! Package will be acording to your requirements?
Q: Could we get the samples?
A: Yes! Definitly! The samples will be sent to you.
