Home > Electrical & Electronics > Electric Motor > DC Motor > O.D 114mm 100% Copper Wire 2KW DC Motor for Electric Forklift
US$ 45 - 50
MOQ: 1 Piece
Key Specifications
Get Latest Price
Brand Name:
Jinle
Model Number:
ZD1221
Type:
Micro Motor
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
O.D 114mm Electric Forklift 2KW DC MotorUS$ 45 - 50MOQ: 1 Piece -
12V Hydraulic Power Pack MotorUS$ 45 - 50MOQ: 1 Piece
-
Hydraulic MotorUS$ 100 - 200MOQ: 1 Piece
-
DC MOTOR 24V 4000W Hydraulic Power Unit Container End Cap SystemUS$ 95 - 100MOQ: 1 Piece
-
3KW Hydraulic 24V Forklift Motor DC TypeUS$ 95 - 100MOQ: 1 Piece
Brand Name
Jinle
Model Number
ZD1221
Type
Micro Motor
Certification
CE
Torque
6N.m
Usage
Boat, Car, Electric Bicycle, Fan, Home Appliance
Construction
Series Wound
Efficiency
IE 4
Protect Feature
Drip-proof
Speed(RPM)
2900RPM
Commutation
Brush
Product Description
O.D 114mm 100% Copper Wire 2KW DC Motor for Electric Forklift
Model: ZD1221
Parameters:
| Model | Voltage(V) | Power(KW) | Speed(RPM) | Rotation | O.D(MM) | Duty |
| QZD2402 | 24 | 2.2 | 1750 | Bi-directional | 164 | S1 |
| QZD2409 | 24 | 0.9 | 2150 | Bi-directional | 126 | S1 |
| QZD2411 | 24 | 1.1 | 2160 | Bi-directional | 127 | S1 |
| QZD2412 | 24 | 2.2 | 1750 | Bi-directional | 164 | S1 |
| QZD2422 | 24 | 2.2 | 1750 | Bi-directional | 164 | S1 |
| QZD2445 | 24 | 4.5 | 1750 | Bi-directional | 180 | S1 |
| QZD4840 | 48 | 4.8 | 1750 | Bi-directional | 218 | S1 |
| QZD4841 | 48 | 4 | 2030 | Bi-directional | 170 | S1 |
| ZD2973A | 24 | 3 | 3100 | CW | 127 | S2 |
| ZD2973 | 24 | 3 | 3100 | CW | 127 | S2 |
| XQD-3C | 24 | 4 | 3100 | CW | 142 | S2 |
| W5692 | 12 | 1.6 | 2500 | CW | 114 | S3 |
| W6599 | 12 | 1.7 | 2720 | CW | 114 | S3 |
| W8799 | 12 | 1.5 | 2400 | CCW | 114 | S3 |
| W8923 | 12 | 1.4 | 2250 | Bi-directional | 114 | S3 |
| W8930B | 12 | 1.5 | 2380 | Bi-directional | 114 | S3 |
| W8935 | 12 | 1.5 | 2460 | CCW | 114 | S3 |
| W8941 | 12 | 1.5 | 2400 | Bi-directional | 114 | S3 |
| W8950 | 24 | 2 | 2600 | CCW | 114 | S3 |
| W8999 | 12 | 1.6 | 2500 | CCW | 114 | S3 |
| W9144 | 12 | 1.5 | 2150 | Bi-directional | 114 | S3 |
| W9405 | 24 | 1.5 | 2400 | CCW | 114 | S3 |
| W9789 | 12 | 1.6 | 2500 | CW | 114 | S3 |
| ZD193A | 12 | 1.6 | 2500 | CCW | 114 | S3 |
| ZD4201 | 48 | 2 | 2700 | CW | 114 | S3 |
| ZD223A | 24 | 2.2 | 2700 | CCW | 114 | S3 |
| ZD1223 | 12 | 2 | 2800 | CW | 114 | S3 |
| ZD293A | 24 | 2.2 | 3000 | CCW | 114 | S3 |
| ZD293 | 24 | 2.2 | 3000 | CW | 114 | S3 |
| ZD2930 | 24 | 2.2 | 2700 | CW | 114 | S3 |
| ZD1221 | 12 | 2 | 2900 | CW | 114 | S3 |
| ZD2931 | 24 | 2 | 2600 | CW | 114 | S3 |
| W7923 | 12 | 1.2 | 1700 | Bi-directional | 114 | S3 |
| ZD223 | 24 | 2.2 | 2700 | CW | 114 | S3 |
| ZDY113 | 12 | 0.8 | 3500 | CW | 80 | S3 |
| ZD2373 | 24 | 3 | 2850 | CW | 125 | S3 |
FAQ
1. Business Type
a. Manufacturer located in Wuxi City, Jiangsu Province
b. Factory cover an area of 6000 square meterselectric forklift motor
c. Employees: over 70 in office & workshops
2. Certificates
CE, ISO9001 etc
3. How long could we get the goods?
a. 10-20days for mass production based on your quantity
b. 5~10days for Sampe orders
4. Quality Control
a. 100% inspection before packing electric forklift motor
b. Spot inspection before shipment
