High Rpm High Power 12v dc Motor With Brush

Wuxi Jinle Automobile Motor Factory
High Rpm High Power 12v dc Motor With Brush thumbnail-1
High Rpm High Power 12v dc Motor With Brush thumbnail-2
High Rpm High Power 12v dc Motor With Brush thumbnail-3
High Rpm High Power 12v dc Motor With Brush photo-1
High Rpm High Power 12v dc Motor With Brush photo-2
High Rpm High Power 12v dc Motor With Brush photo-3
US$ 45 - 50 MOQ: 1 Piece
Key Specifications
Get Latest Price
Brand Name:
Jinle
Place of Origin:
Jiangsu, China
Model Number:
W8999
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
SHANGHAI
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name Jinle
Place of Origin Jiangsu, China
Model Number W8999
Certification CE
Torque 6NM
Usage Boat, Car, Electric Bicycle, Fan, Home Appliance
Construction Series Wound
Efficiency IE 4
Protect Feature Drip-proof
Voltage(V) 12v
Output Power 1.6kw
Continuous Current(A) 120A
Speed(RPM) 2500RPM
Commutation Brush

high rpm high power 12v dc motor with brush




Product Description



Features:

Slot Shaft

2 field coil high rpm motor

Thru Bolts are at 5 and 11 O'clock

100% copper wire

stable running, high efficiency, low noise

good service after sale

12V, 24V, 48V, 60V etc.  on your request

Customized production is available!

Supply for OEM Production!

nearly 20 years' manufacturing experience



Applications:

Anthony Equipment, Haldex/Barnes, Waltco, Monarch Hydrauclics, MTE Hydraulics



Specification:

TypeVoltagePowerSpeedRotationO.D.Operating ModeTorque
W899912V16KW2500RPMCCW114mmS36N.m

LESTER 10751

PIC 160-843

WAI 82-6854-1

Replaces: MTE Hydraulics 39200292, -380

                Prestolote 46-3620, MUE6201, MUE6301

                     WAPSA9130450061, -64, -81


high rpm high power 12v dc motor with brushhigh rpm high power 12v dc motor with brush



 high rpm high power 12v dc motor with brush







Our Services



1) Low noise
2) Easy brush replacement
3) OEM service avaliable
4) Efficient and long continuous running time

5) Customization available

6) Robust construction for long and reliable service life
7) 100% copper wire

8) 12V, 24V, 36V, 48V,60V,72V as per customers' option

9) Factory established in 1996 with nearly 20 years' manufacturing experience





Certifications







  OHTER TYPES





TypeVoltagePowerSpeedRotaionO.D.
W569212V1.6KW2500RPMCW114mm
W659912V1.7KW2720RPMCW114mm
W978912V1.6KW2500RPMCW114mm
ZD420148V2.0KW2700RPMCW114mm
ZD122312V2.0KW2800RPMCW114mm
ZD29324V2.2KW3000RPMCW114mm
ZD293024V2.2KW2700RPMCW114mm
ZD122112V2.0KW2900RPMCW114mm
ZD293124V2.0KW2600RPMCW114mm
ZD223A24V2.2KW2700RPMCW114mm
ZDY21124V0.8KW3650RPMCW80mm
ZDY21224V0.5KW2800RPMCW80mm
ZDY11212V0.5KW2300RPMCW80mm
ZDY11312V0.8KW3500RPMCW80mm
ZD2973A24V3.0KW3100RPMCW127mm
ZD2973A24V3.0KW3100RPMCW127mm
ZD237324V3.0KW2850RPMCW125mm
XQD-3C24V3.5KW3100RPMCW142mm
TypeVoltagePowerSpeedRotaionO.D.
W879912V1.5KW2400RPMCCW114mm
W893512V1.5KW2460RPMCCW114mm
W895024V2KW2600RPMCCW114mm
W899912V1.6KW2500RPMCCW114mm
W940524V1.5KW2400RPMCCW114mm
ZD193A12V1.6KW2500RPMCCW114mm
ZD223A24V2.2KW2700RPMCCW114mm
ZD293A24V2.2KW3000RPMCCW114mm
TypeVoltagePowerSpeedRotaionO.D.
QZD240224V2.2KW1750RPMBI-DIRECTIONAL164mm
QZD240924V0.9KW2150RPMBI-DIRECTIONAL126mm
QZD241124V1.1KW2160RPMBI-DIRECTIONAL127mm
QZD241224V2.2KW1750RPMBI-DIRECTIONAL164mm
QZD242224V2.2KW1750RPMBI-DIRECTIONAL164mm
QZD244524V4.5KW1750RPMBI-DIRECTIONAL180mm
QZD484048V4.8KW1750RPMBI-DIRECTIONAL218mm
QZD484148V4.0KW2030RPMBI-DIRECTIONAL170mm
W892312V1.4KW2250RPMBI-DIRECTIONAL114mm
W8930B12V1.5KW2380RPMBI-DIRECTIONAL114mm
W894112V1.5KW2400RPMBI-DIRECTIONAL114mm
W914412V1.5KW2150RPMBI-DIRECTIONAL114mm
W792312V1.2KW1700RPMBI-DIRECTIONAL114mm







Company Information

 Our factory was established in 1996,  professional in forklift motors, hydraulic power unit motors.



We have nearly 20 years' manufacturing experience with a strong team of 30 engineers for development and research. The motors' annual output has been more than 200,000 sets.



So far, we are the only designated OEM hydraulic power unit motor supplier in China for US WAI Company, OEM forklift motor supplier for Korea SOOSUNG. Also, we cooperated Korea KOPACK and HELI in China.



  high rpm high power 12v dc motor with brush

FAQ



1. Business Type

a. Manufacturer located in Wuxi City, Jiangsu Province
b. Factory cover an area of 6000 square meterselectric forklift motor
c. Employees: over 70 in office & workshops



2. Certificates

CE, ISO9001 etc



3. How long could we get the goods?

a. 10-20days for mass production based on your quantity
b. 5~10days for Sampe orders



4. Quality Control

a. 100% inspection before packing electric forklift motor
b. Spot inspection before shipment









 high rpm high power 12v dc motor with brush
