Home > Electrical & Electronics > Electric Motor > DC Motor > 24VDC MOTOR 2.2KW FOR Lifting Forklift Pump Power Unit

24VDC MOTOR 2.2KW FOR Lifting Forklift Pump Power Unit

Wuxi Jinle Automobile Motor Factory
24VDC MOTOR 2.2KW FOR Lifting Forklift Pump Power Unit thumbnail-1
24VDC MOTOR 2.2KW FOR Lifting Forklift Pump Power Unit thumbnail-2
24VDC MOTOR 2.2KW FOR Lifting Forklift Pump Power Unit thumbnail-3
24VDC MOTOR 2.2KW FOR Lifting Forklift Pump Power Unit thumbnail-4
24VDC MOTOR 2.2KW FOR Lifting Forklift Pump Power Unit thumbnail-5
24VDC MOTOR 2.2KW FOR Lifting Forklift Pump Power Unit photo-1
24VDC MOTOR 2.2KW FOR Lifting Forklift Pump Power Unit photo-2
24VDC MOTOR 2.2KW FOR Lifting Forklift Pump Power Unit photo-3
24VDC MOTOR 2.2KW FOR Lifting Forklift Pump Power Unit photo-4
24VDC MOTOR 2.2KW FOR Lifting Forklift Pump Power Unit photo-5
US$ 35 - 40 MOQ: 1 Piece
Key Specifications
Get Latest Price
Brand Name:
Jinle
Place of Origin:
Jiangsu, China
Type:
Micro Motor
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
SHANGHAI
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name Jinle
Place of Origin Jiangsu, China
Type Micro Motor
Certification CE
Torque 6NM
Usage Boat, Car, Electric Bicycle, Fan, Home Appliance
Construction Series Wound
Efficiency IE 4
Protect Feature Drip-proof
Voltage(V) 24v
Continuous Current(A) 120A
Speed(RPM) 2150RPM
Commutation Brush

24VDC MOTOR 2.2KW FOR Lifting forklift pump power unit





Product Description

Features of hydraulic dc motor 24v, 24V DC Motor 2.2KW , JINLE Brand DC MOTORS :

24V DC MOTOR

100% copper wire

stable running, high efficiency, low noise

good service after sale

12V, 24V, 48V, 60V etc.  on your request

Customized production is available!

Supply for OEM Production!

nearly 20 years' manufacturing experience

Can be used for power pack unit

Specification of hydraulic dc motor 24v, 24V 2.2KW DC MOTORS:

Model/Type : ZD223A

Voltage:    24v

Power: 2.2kw

Speed: 2700RPM

Rotation: CCW

O.D.:   114mm



24VDC MOTOR 2.2KW FOR Lifting forklift pump power unit

 24VDC MOTOR 2.2KW FOR Lifting forklift pump power unit





24VDC MOTOR 2.2KW FOR Lifting forklift pump power unit



Other models:

TypeVoltagePowerSpeedRotaionO.D.Torque
W569212V1.6KW2500RPMCW114mm6N.m
W659912V1.7KW2720RPMCW114mm6N.m
W978912V1.6KW2500RPMCW114mm6N.m
ZD420148V2.0KW2700RPMCW114mm6N.m
ZD122312V2.0KW2800RPMCW114mm6N.m
ZD29324V2.2KW3000RPMCW114mm6N.m
ZD293024V2.2KW2700RPMCW114mm6N.m
ZD122112V2.0KW2900RPMCW114mm6N.m
ZD293124V2.0KW2600RPMCW114mm6N.m
ZD223A24V2.2KW2700RPMCW114mm6N.m
ZDY21124V0.8KW3650RPMCW80mm2N.m
ZDY21224V0.5KW2800RPMCW80mm2N.m
ZDY11212V0.5KW2300RPMCW80mm2N.m
ZDY11312V0.8KW3500RPMCW80mm2N.m
ZD2973A24V3.0KW3100RPMCW127mm10N.m
ZD237324V3.0KW2850RPMCW125mm10N.m
XQD-3C24V3.5KW3100RPMCW142mm10N.m
W879912V1.5KW2400RPMCCW114mm6N.m
W893512V1.5KW2460RPMCCW114mm6N.m
W895024V2KW2600RPMCCW114mm6N.m
W899912V1.6KW2500RPMCCW114mm6N.m
W940524V1.5KW2400RPMCCW114mm6N.m
ZD193A12V1.6KW2500RPMCCW114mm6N.m
ZD223A24V2.2KW2700RPMCCW114mm6N.m
ZD293A24V2.2KW3000RPMCCW114mm6N.m
QZD241124V1.1KW2160RPMBI-DIRECTIONAL127mm10N.m
QZD484148V4.0KW2030RPMBI-DIRECTIONAL170mm17N.m
W892312V1.4KW2250RPMBI-DIRECTIONAL114mm6N.m
W8930B12V1.5KW2380RPMBI-DIRECTIONAL114mm6N.m
W894112V1.5KW2400RPMBI-DIRECTIONAL114mm6N.m
W914412V1.5KW2150RPMBI-DIRECTIONAL114mm6N.m
W792312V1.2KW1700RPMBI-DIRECTIONAL114mm6N.m
125912V50W500RPMCW56mm0.5N.m
N246324V200W3000RPMBI-DIRECTIONAL63mm1N.m
ZDY11812V1.2KW3000RPMCW80mm2N.m
ZDY21824V1.2KW3000RPMCW80mm2N.m
ZDY41848V1.2KW3000RPMCW80mm2N.m
MA08XXN12V0.8KW3200RPMBI-DIRECTIONAL80mm2N.m
MB08XXN24V0.8KW3000RPMBI-DIRECTIONAL80mm2N.m
ZDY211S24V0.8KW3100RPMCCW80mm2N.m
N161212V1.6KW2350RPMCW114mm6N.m
N202424V2.2KW2700RPMCW114mm6N.m
ZD123012V1.6KW2350RPMCW114mm6N.m
ZD242024V2.2KW2700RPMCW114mm6N.m
ZD620260V2.0KW2600RPMCW114mm6N.m
ZD720272V2KW2600RPMCW114mm6N.m
MD1216012V1.6KW2700RPMCW114mm6N.m
ZD124112V1.6KW2350RPMCW114mm6N.m
ZD294124V2.2KW2700RPMCW114mm6N.m
N302424V3.0KW3000RPMCW127mm10N.m
Packaging & Shipping

 24VDC MOTOR 2.2KW FOR Lifting forklift pump power unit



24VDC MOTOR 2.2KW FOR Lifting forklift pump power unit





Our Services



1) Low noise
2) Easy brush replacement
3) OEM service avaliable
4) Efficient and long continuous running time

5) Customization available

6) Robust construction for long and reliable service life
7) 100% copper wire

8) 12V, 24V, 36V, 48V,60V,72V as per customers' option

9) Factory established in 1996 with nearly 20 years' manufacturing experience





Certifications









Company Information



Our factory was established in 1996,  professional in forklift motors, hydraulic power unit motors.



We have nearly 20 years' manufacturing experience with a strong team of 30 engineers for development and research. The motors' annual output has been more than 200,000 sets.



So far, we are the only designated OEM hydraulic power unit motor supplier in China for US WAI Company, OEM forklift motor supplier for Korea SOOSUNG. Also, we cooperated Korea KOPACK and HELI in China.











FAQ



1. Business Type

a. Manufacturer located in Wuxi City, Jiangsu Province
b. Factory cover an area of 6000 square meterselectric forklift motor
c. Employees: over 70 in office & workshops



2. Certificates

CE, ISO9001 etc



3. How long could we get the goods?

a. 10-20days for mass production based on your quantity
b. 5~10days for Sampe orders



4. Quality Control

a. 100% inspection before packing electric forklift motor
b. Spot inspection before shipment













  Some of other models:



24VDC MOTOR 2.2KW FOR Lifting forklift pump power unit     24VDC MOTOR 2.2KW FOR Lifting forklift pump power unit

24VDC MOTOR 2.2KW FOR Lifting forklift pump power unit     24VDC MOTOR 2.2KW FOR Lifting forklift pump power unit





 24VDC MOTOR 2.2KW FOR Lifting forklift pump power unit
