Brushless dc Motor High Rpm 48v High Speed Low Torque Bldc Motor BMM713

Brushless dc Motor High Rpm 48v High Speed Low Torque Bldc Motor BMM713 photo-1
Brushless dc Motor High Rpm 48v High Speed Low Torque Bldc Motor BMM713 photo-2
US$ 44 - 68 MOQ: 2 Pieces
Key Specifications
Get Latest Price
Brand Name:
McMaster
Place of Origin:
Jiangsu, China
Model Number:
BMM713
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai Ningbo
Delivery Detail:
Delivery time depends on order quantity.
Brand Name McMaster
Place of Origin Jiangsu, China
Model Number BMM713
Type Micro Motor
Certification CCC, ROHS
Torque 2 N.m
Usage Boat, Car, Fan, Home Appliance
Construction Permanent Magnet
Efficiency IE 2
Protect Feature Totally Enclosed
Continuous Current(A) 15 A
Speed(RPM) 2500 rpm
Commutation Brushless
Product Description

brushless dc motor high rpm 48v high speed low torque bldc motor BMM713



OUR PRODUCTS



brushless dc motor high rpm 48v high speed low torque bldc motor BMM713

Product:brushless dc motor high rpm 48v high speed low torque bldc motor

Product Application: medical equipment, logistics transmission, mechanical equipment, solar tracking device  etc.





brushless dc motor high rpm 48v high speed low torque bldc motor BMM713



SPECIFICATIONS



Model

Voltage

(VDC)

No Load

Rated Load

Toque

(N.m)

Cogging

Torque

(Nm)

Moment of Inertia

(Kg.cm2)

Torque Constant

(N.m/A)

Power

(W)

Length

(mm)

Current

(A)

Speed

(r/min)

Current

(A)

Speed

(r/min)

BMM713-1

48

2.47

2941

14.54

2500

2

0.16

2.8

0.166

524

96

BMM713-2

150

1.19

2941

6.98

2500

3

0.24

4.2

0.518

785

121



PERFORMANCE CURVE

brushless dc motor high rpm 48v high speed low torque bldc motor BMM713

OUTLINE DRAWING

brushless dc motor high rpm 48v high speed low torque bldc motor BMM713

SIMILAR PRODUCT



Similar Power









BMM716











Similar Speed





BMM703

BMM711

BMM717

BMM722

BMM754



Similar Torque





BMM716

BMM717

BMM729

BMM754

BMM755

BMM902

For more information, you can visit our website
Packaging & Shipping

Each motor is packed in a foam box, 3pcs in a carton and 45 cartons in a pallet. If you have any special needs, please let us know, we can design packaging according to your request.brushless dc motor high rpm 48v high speed low torque bldc motor BMM713
