Home > Electrical & Electronics > Electric Motor > DC Motor > 220V 50/60Hz 4000W High Torque 3 Phase AC Servo Motor 3000rpm E663
220V 50/60Hz 4000W High Torque 3 Phase AC Servo Motor 3000rpm E663
US$ 120 - 197.9
MOQ: 2 Pieces
Key Specifications
Get Latest Price
Brand Name:
McMaster
Place of Origin:
Jiangsu, China
Model Number:
E663
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai Ningbo
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
220V 50/60Hz 1000W 3-phase High Torque 3600rpm Step Servo Motor E664US$ 77.6 - 128.1MOQ: 2 Pieces -
12S Brushless dc Motor 6354 for Mountainboard/e-skateboard/electric Scooter 190KV to 270KV BMM942US$ 25.5 - 31.97MOQ: 1 Piece
-
DC Gear Motor 24V 65W Low Rpm Electric DC Reducer Motor BMM233US$ 48 - 54MOQ: 2 Pieces
-
Golden Supplier 12V dc 10kg.cm 38mm Worm Gear Motor 50 RPM Gear Motor With Gearbox Reducer for Door OpenerUS$ 15.5 - 19MOQ: 2 Pieces
-
12V 24V dc Small Type 37mm Gear Motor 100Kg.cm Worm Gear Motor for BBQ EquipmentUS$ 16 - 20MOQ: 2 Pieces
Brand Name
McMaster
Place of Origin
Jiangsu, China
Model Number
E663
Type
Servo Motor
Certification
CCC, ROHS
Efficiency
IE 2
Protect Feature
Totally Enclosed
Product Description
Speed/Position Detector:Photoelectric Encoder 2500p/rev
Structure:Totally Enclosed Self-cooling(Protection Class IP65)
Working Voltage AC(V):Three phases 220V-15%-+10% 50/60Hz(300V)
Manner of Working:Continuous
Insulation Class:F
Ambient Temperature:0-40°C(Not Freeze),Keep:-25-70°C(Not Freeze)
Humidity:Below 80%RH(Non-condensate),Keep:Below 90%RH(Non-condensate)
Ambient Condition:Indoor (not directly affected by sunshine),away from corrosive gases, flammable
Height:Elevation below 5000m
Vibration:Axial:24.5m/S² Radial:49 m /S²
| model |
Voltage (VAC) |
Rated Current (A) |
Max Current (A) |
Rated speed (rpm) |
Max speed (rpm) |
Rated Torque (N.m) |
Max Torque (N.m) |
Rated Power (w) |
Rotor Inertia (kg.cm²) |
Weight (kg) |
| E663-M4025 |
Three phases 220V-15%-+10% 50/60Hz |
4 | 12 | 2500 | 3000 | 4 | 12 | 1047 | 11 | 6.1 |
| E663-M5025 | 5 | 15 | 2500 | 3000 | 5 | 15 | 1300 | 12 | 7.1 | |
| E663-M6025 | 6 | 18 | 2500 | 3000 | 6 | 18 | 1571 | 13.3 | 7.6 | |
| E663-M7525 | 7.5 | 22 | 2500 | 3000 | 7.5 | 22.8 | 1963 | 18.2 | 8.4 | |
| E663-M7720 | 6 | 18 | 2000 | 2500 | 7.7 | 23.1 | 1613 | 18.2 | 8.5 | |
| E663-M10025 | 10 | 30 | 2500 | 3000 | 10 | 30 | 2618 | 24 | 10.8 | |
| E663-M15015 | 9 | 27 | 1500 | 2000 | 15 | 39 | 2356 | 35 | 14 | |
| E663-M15025 | 15 | 45 | 2500 | 3000 | 15 | 39 | 3927 | 35 | 14 |
Each motor is packed in a foam box, 3pcs in a carton and 45 cartons in a pallet. If you have any special needs, please let us know, we can design packaging according to your request.
