Home > Electrical & Electronics > Electric Motor > DC Motor > 350W 300rpm DC Motor With Gearbox 24V High Torque Planetary Reduction Gear Motor for Solar Tracker BMM525M
350W 300rpm DC Motor With Gearbox 24V High Torque Planetary Reduction Gear Motor for Solar Tracker BMM525M
US$ 124 - 197
MOQ: 2 Pieces
Key Specifications
Get Latest Price
Brand Name:
Mcmaster
Place of Origin:
Jiangsu, China
Model Number:
BMM525M
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai Ningbo
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
BMF044W 230 V 380 V Dia 200 mm External Rotor Air Blowers Axial Ventilation Electric Fan for CNC LatheUS$ 30 - 30MOQ: 2 Pieces -
BMF044W 230 V 380 V Dia 200 mm External Rotor Air Blowers Axial Ventilation Electric Fan for CNC LatheUS$ 30 - 30MOQ: 2 Pieces
-
24V BLDC Reducer Motor With Gearbox OD 56mm Brushless Planetary Reduction Gear Motor for Robot BMM905MUS$ 39 - 75MOQ: 2 Pieces
-
BEBFR26EW Powerful European Standard Long Range Fat Tire Outdoor E Bike Electric BicycleUS$ 630 - 680MOQ: 1 Piece
-
EMM632W Hot Sale OD127mm 24V 3000w 3000 Rpm High Rpm Hydraulic dc Motors for PumpUS$ 99.8 - 157.5MOQ: 2 Pieces
Brand Name
Mcmaster
Place of Origin
Jiangsu, China
Model Number
BMM525M
Type
Gear Motor
Certification
CCC, ROHS
Torque
10N.M
Usage
Boat, Car, Electric Bicycle, Fan, Home Appliance
Construction
Permanent Magnet
Efficiency
IE 2
Protect Feature
Totally Enclosed
Continuous Current(A)
21 A
Speed(RPM)
330 RPM
Commutation
Brush
|
VOLTAGE (V) |
NO LOAD |
RATED LOAD |
Torque (N.m) |
RATIO |
STAGE |
Power (W) |
LENGTH (mm) |
|||
|
CURRENT (A) |
SPEED (r/min) |
CURRENT (A) |
SPEED (r/min) |
|||||||
|
BMM525M |
24 |
4.85 |
402 |
21.82 |
333 |
10.8 |
6 |
1 |
377 |
287 |
|
Voltage (VDC) |
No Load |
Rated Load |
Toque (N.m) |
EMF constant (V/rpm) |
torque constant (N.m/A) |
Length (mm) |
||
|
Current(A) |
Speed(r/min) |
Current(A) |
Speed(r/min) |
|||||
|
24 |
4.36 |
2409 |
21.82 |
2000 |
2 |
0.0120009 | 0.1146 | 224 |
