24V 65W DC Reducer Motor with Gearbox Low rpm DC Gear Motor BMM227M

Name: 24V 65W DC Reducer Motor with Gearbox Low rpm DC Gear Motor BMM227M
Brand: Mcmaster
Price: USD $53 - 75 / Piece

FOB Price

USD $53 - $75 / Piece

2 Pieces(Min.Order)

Supply Ability 1000 Piece / Pieces per Month
Port Shanghai Ningbo
Payment Terms:T/T Credit Card

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price Inquiry Basket

Product Details

Brand Name:	Mcmaster	Place of Origin:	Jiangsu, China	Model Number:	BMM227M
Type:	Gear Motor	Certification:	CCC, ROHS	Torque:	1 N.m- 7.5 N.m
Usage:	Boat, Car, Electric Bicycle, Fan, Home Appliance	Construction:	Permanent Magnet	Efficiency:	IE 2
Protect Feature:	Totally Enclosed	Output Power:	30W - 65W	Continuous Current(A):	1.3 A - 2.7 A
Speed(RPM):	20 rpm - 300 rpm	Commutation:	Brush

Product Description

Product Application: Outdoor advertising, medical equipment, logistics transmission, mechanical equipment, solar tracking device, precision equipment etc.

RATIO TORQUE(Nm) SPEED(r/min)	1/10	1/15	1/20	1/25	1/40	1/75	1/100	VOLTAGE (VDC)	CURRENT(mA)		Power (W)	LENGTH (mm)
RATIO TORQUE(Nm) SPEED(r/min)	1	1.2	1.6	2	3.2	5.5	7.5	VOLTAGE (VDC)	NO LOAD	RATED LOAD	Power (W)	LENGTH (mm)
BMM227M-1	200	133	100	80	50	26	20	24	≤200	≤1300	31.2	105.9
BMM227M-2	300	200	150	120	75	40	30	24	≤400	≤2700	65	105.9
