Introductions:
ES-F series electric folding steps are designed to fit on range of vans, minibuses, motorhomes, ambulances and so on.
It can help passengers to get on vehicles easily.
It's driven by motor, voltage can be 12Vdc or 24Vdc.
The main material is aluminum which is light and has good corrosion resistance.
It can be operated by a switch or gang controlled by door.
This step can work steadily, reliably and safely.
We have single folding step, double folding step and triple folding step.
We have different steps with several specifications, which can meet different requirements.
Advantages:
CE and EMARK certified;
Manual emergency function;
Door interlock function;
Sensitive edge;
15kg sensitive loading function;
Warning sound during working
Auto sleep mode;
Low static power consumption, quiescent current is less than 0.2mA;
Warning in case of improper installation;
Self-protection in case of wrong connection;
LED and LED cover are equipped as standard
Volatage: 12Vdc or 24Vdc;
Power: 30W;
Loading capacity: 200Kg;
unit: mm
| model | gross depth |
gross thickness |
step width |
step depth |
height (unfold) |
gross wodth |
| ES-F-S-450*300 | 500 | 180 | 450 | 300 | 230 | 476 |
| ES-F-S-600*300 | 500 | 180 | 600 | 300 | 230 | 626 |
note: we can make step depth D as 235mm
