BSP thread 3/8 inch high speed rotary union for hydraulic oil,water,air
- 10000 Piece / Pieces per Month
- Qingdao
- T/T L/C D/P D/A Credit Card PayPal Other Cash Escrow
- 15 days
- 360 degree rotation high pressure hydraulic water swivel joint DIN flange connection
- High temperature high pressure stainless steel 304 metal braided hose DIN flange connection
- Female X Female connection stainless steel 304 high temperature steam metal braided hose
- High temperature steam flexible metal braided hose with bell mouth internal thread connection is used in printing and dyeing industry
- Flange connection high pressure stainless steel metal braided hose used in industry
- Stainless steel flexible metal braided hose for automobile exhaust pipe can be customized in size and length
Product Details
Brand Name: | Jieyi | Place of Origin: | China | Model Number: | JYHS0102-10A high speed rotary union |
Material: | Stainless Steel | Type: | Union | Shape: | Other, Round |
Technics: | Forged | Connection: | Male | Head Code: | Other, Round |
Product Description
BSP thread 3/8 inch high speed rotary union for hydraulic oil,water,air
Use parameters | |
Pressure | 350 bar / 35 MPa |
Temperature | 120 ℃ / 248 °F |
Speed | 1000 rpm |
Media | Water, Gas, Oil |
Size | 1/4'' ~ 2''; or customized |
Connection | Thread |
Standard | BSPP, BSPT, NPT |
Seal | Imported seal |
Bearing | NSK, SKF, HRB |
Material | SS304 / Carbon steel |
Product name | Water rotary joint |
Product Features
Monoflow
Self-supported rotating union
Radial housing connection
Balanced mechanical seal
Stainless steel housing
Special options: threaded vent holes, low torque design
Seal Combinations:
Standard: Carbon Graphite/Bronze for water
Optional: Carbon Graphite/Ceramic for hot oil, hot water and saturated steam
E.L.S.: Tungsten Carbide/Ceramic for severe conditions (poor water quality), max. temperature 350°F
Product show
