Chinese Supplier Bridge Bearings 22218 Spherical Roller Bearing

Chinese Supplier Bridge Bearings 22218 Spherical Roller Bearing thumbnail-1
Chinese Supplier Bridge Bearings 22218 Spherical Roller Bearing thumbnail-2
Chinese Supplier Bridge Bearings 22218 Spherical Roller Bearing thumbnail-3
Chinese Supplier Bridge Bearings 22218 Spherical Roller Bearing thumbnail-4
Chinese Supplier Bridge Bearings 22218 Spherical Roller Bearing thumbnail-5
Chinese Supplier Bridge Bearings 22218 Spherical Roller Bearing thumbnail-6
Chinese Supplier Bridge Bearings 22218 Spherical Roller Bearing photo-1
Chinese Supplier Bridge Bearings 22218 Spherical Roller Bearing photo-2
Chinese Supplier Bridge Bearings 22218 Spherical Roller Bearing photo-3
Chinese Supplier Bridge Bearings 22218 Spherical Roller Bearing photo-4
Chinese Supplier Bridge Bearings 22218 Spherical Roller Bearing photo-5
Chinese Supplier Bridge Bearings 22218 Spherical Roller Bearing photo-6
US$ 2.69 - 3 MOQ: 100 Sets
Key Specifications
Get Latest Price
Brand Name:
CLUNT
Place of Origin:
Shandong, China
Model Number:
22218
Contact Supplier Request Quote Chat Now
Jinan Kelunte Bearing Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao/Shenzhen Port
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name CLUNT
Place of Origin Shandong, China
Model Number 22218
Number of Row Double Row
Seals Type OPEN ZZ 2RS
Precision Rating ABEC5. ABEC7, ABEC9
chinese supplier bridge bearings 22218 spherical roller bearing
Product Description

chinese supplier bridge bearings 22218 spherical roller bearing



chinese supplier bridge bearings 22218 spherical roller bearing chinese supplier bridge bearings 22218 spherical roller bearing



1.SPECIFICATION OF SPHERICAL ROLLER BEARING 22218 CA

Designation: 22218 CA
Type: Radial spherical roller bearings. Multi row. Complete. (90X160X40).
Main dimensions:
d mm D mm B mm Speed Ratings-Grease(r/min) Speed Ratings-Oil(r/min) Dynamic Load Ratings(KN) Static Load Ratings(KN) Mass kg
90.000 160.000 40.000 1900 2600 249 337 3.415





2.PRODUCT DESCRIPTION

Self-aligning roller bearing has two rows of spherical rollers, the outer race is provided with a common concave spherical raceway, while the inner race is provided with two concave spherical raceways that form an angle with the bearing axis. The curvature center of the outer raceway is consistent with the bearing center.



The self-aligning roller bearing is self-adjusted, and it is not affected by non-centering or shaft deformation flexure of shaft and bearing block, so it can compensate the concentricity error caused by these reasons. Except being subject to radial load, this type of bearing can also be subject to bidirectional axial load and their combination load. The load capacity is large, and the bearing is provided with preferable shock resistant capacity.



Self-aligning roller bearings are mainly applied on mechanical equipments of steel, mine, paper making, shipping, textile machinery, coal mill and electric power industries. It is one of the bearings most widely used in mechanical industry.





3. 22000 23000 SELF-ALIGNING ROLLER BEARINGS SERIES - 22218

 chinese supplier bridge bearings 22218 spherical roller bearingchinese supplier bridge bearings 22218 spherical roller bearingchinese supplier bridge bearings 22218 spherical roller bearingchinese supplier bridge bearings 22218 spherical roller bearingchinese supplier bridge bearings 22218 spherical roller bearing

specification

dimensions(mm)

specification

dimensions(mm)

22205

25*52*18

23064

320*480*121

22206

30*62*20

23068

340*520*133

22207

35*72*23

23072

360*540*134

22208

40*80*23

23076

380*560*135

22209

45*85*23

23080

400*600*148

22210

50*90*23

23084

420*620*150

22211

55*100*25

23088

440*650*157

22212

60*110*28

23092

460*680*163

22213

65*120*31

23096

480*700*165

22214

70*125*31

230/500

500*720*167

22215

75*130*31

230/530

530*780*185

22216

80*140*33

230/560

560*780*195

22217

85*150*36

230/600

600*870*200

22218

90*160*40

230/630

630*920*212

22219

95*170*43

230/670

670*980*230

22220

100*180*46

240/850

850*1220*365

22222

110*200*53

240/900

900*1280*375

22224

120*215*58

23121

105*175*56

22226

130*230*64

23122

110*180*56

22228

140*250*68

23124

120*200*62

22230

150*270*73

23126

130*210*80

22232

160*260*80

23128

140*225*85

22234

170*310*86

23130

150*250*80

22236

180*320*86

23132

160*270*86

22238

190*320*92

23134

170*280*88

22240

200*360*98

23136

180*300*96

22244

220*400*108

23138

190*320*104

22248

240*440*120

23140

200*340*112

22252

260*480*130

23144

220*370*120

22256

280*500*130

23148

240*400*128

22260

300*540*140

23152

260*440*144

22308

40*90*33

23156

280*460*146

22309

45*90*33

23160

300*500*160

22310

50*110*40

23164

320*540*176

22311

55*120*43

23168

340*580*190

22312

60*130*46

23172

360*600*192

22313

65*140*48

23176

380*620*194

22314

70*150*51

23180

400*650*200

22315

75*160*55

23184

420*700*224

22316

80*170*58

23188

440*720*226

22317

85*180*60

23192

460*760*240

22318

90*190*64

23196

480*790*248

22319

95*200*67

23218

90*160*52.4

22320

100*215*73

23220

100*180*60.3

22322

110*240*80

23222

100*180*60.3

22324

120*246*80

23224

120*200*69.8

22326

130*280*93

23226

120*230*80

22328

140*300*102

23228

140*250*88

22330

150*320*108

23230

150*270*96

22332

1608340*114

23232

160*290*104

22334

170*360*120

23234

180*310*110

22336

180*380*126

23236

180*320*112

22338

190*400*132

23238

190*340*120

22340

200*420*138

23240

200*360*128

22344

220*4608145

23244

200*400*144

22348

240*500*155

23248

240*440*160

22352

260*540*165

23252

260*480*174

22356

280*580*175

23256

280*500*176

22372

360*750*244

23260

300*540*192

22380

400*820*243

23264

320*580*208

23022

110*170*75

23280

400*720*256

23024

120*180*46

23284

420*760*272

23026

130*200*52

23296

480*870*310

23028

140*210*53

23936

180*250*52

23030

150*225*56

23940

200*280*60

23032

160*240*60

23948

240*320*60

23034

170*260*67

23960

300*420*90

23036

180*280*74

23972

360*480*90

23038

190*290*75

23976

380*580*106

23040

200*310*82

23996

480*650*128

23044

230*340*90

239/500

500*670*128

23048

240*360*92

239/670

670*900*170

23052

260*400*104

239/710

710*950*180

23056

280*420*106

239/850

850*1200*200

23060

300*460*118







4.PRODUCTS PICTURES



chinese supplier bridge bearings 22218 spherical roller bearingchinese supplier bridge bearings 22218 spherical roller bearing

more product

Packaging & Shipping

Packing &Delivery





Our Services







Company Information

 Jinan Kelunte Bearing Co., Ltd. is a professional deep groove ball bearing manufacturer and is engaged in the imported bearings.Our company is engaged in the imported bearings,company's main imported Roller Bearing,Ball Bearing,deep groove ball bearings,taper roller bearings,angular contact ball bearings,Pillow Block Bearing etc.
