US$ 4 - 6 MOQ: 1 Set
Key Specifications
Get Latest Price
Brand Name:
CLUNT
Place of Origin:
Shandong, China
Model Number:
25583/25519
Contact Supplier Request Quote Chat Now
Jinan Kelunte Bearing Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
QINGDAO GUANGDONG SHANGHAI
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name CLUNT
Place of Origin Shandong, China
Model Number 25583/25519
Number of Row Single Row
Seals Type open
Precision Rating P0 P6 P5 P4 P2



Chinese Inch Bearing SET256 Taper Roller Bearing 25583/25519 Bearing





Industries:
Aerospace, agriculture, automotive, heavy truck, cement, aggregate, coal, oil and gas, construction, gear drives, machine tools, mining, paper, metals, rail and wind.

Benefits:
Enhanced performance in demanding applications.

Tapered roller bearings 25583/25519

Bearing number : 25583/25519

Size (mm) : 44.45x82.55x34.29

Brand : CLUNTE

Bore Diameter (mm) : 44,45

Outer Diameter (mm) : 82,55

Width (mm) : 34,29

Bearing dimensions and specification in  catalogue:



d - 44,45 mm

D - 82,55 mm

T - 34,29 mm

B - 35,878 mm

C - 19,05 mm

R - 3,8 mm

r - 2 mm

Weight - 0,66 Kg




Your inquiry related to our product & price will be replied within 24 hours.



  • Well-trained & experienced staff are to answer all your inquiries in English of course.
  • Working time: 8:30am ~12:00pm, Monday to Sunday(UTC+8).
  • OEM projects are highly welcomed. We have professional team here to help.







Chinese Inch Bearing SET256 Taper Roller Bearing 25583/25519 BearingChinese Inch Bearing SET256 Taper Roller Bearing 25583/25519 BearingChinese Inch Bearing SET256 Taper Roller Bearing 25583/25519 BearingChinese Inch Bearing SET256 Taper Roller Bearing 25583/25519 BearingChinese Inch Bearing SET256 Taper Roller Bearing 25583/25519 BearingChinese Inch Bearing SET256 Taper Roller Bearing 25583/25519 Bearing

Features of Taper Roller Bearing:



High radial and axial loads in one direction
Medium speeds
Small clearance range when bearing pairs are adjusted during mounting
Higher permissible speeds by improved raceway surface roughness
Metric and imperial dimensions
Outer diameters up to 2500 mm
cage optimised for large taper roller bearings installed in planetary carriers
Hardened high carbon chromium steel





Bearing Principal Dimensions (mm) Basic Load Ratings (N) Limiting Speeds (r/min) Mass
No. d D T B C Dynamic (Cr) Static (C0r) Grease Oil kg
32004 20 42 15 15 12 19360 21600 6800 9600 0.097
320/22 22 44 15 15 11.5 20080 23200 6400 8800 0.1
32005 25 47 15 15 11.5 21600 26000 6400 8800 0.11
320/28 28 52 16 16 12 25520 30400 5600 7600 0.15
32006 30 55 17 17 13 28640 35200 5360 7200 0.17
320/32 32 58 17 17 13 29520 37200 5040 6800 0.19
32007 35 62 18 18 14 34320 43200 4800 6400 0.22
32008 40 68 19 19 14.5 42240 56800 4240 5600 0.27
32009 45 75 20 20 15.5 46640 64000 3840 5040 0.34
32010 50 80 20 20 15.5 48400 70400 3600 4800 0.37
32011 55 90 23 23 17.5 64720 92800 3200 4240 0.55
32012 60 95 23 23 17.5 66000 97600 3040 4000 0.59
32013 65 100 23 23 17.5 67360 101600 2720 3600 0.63
32014 70 110 25 25 19 80800 122400 2560 3440 0.84
32015 75 115 25 25 19 84800 130400 2400 3200 0.9
32016 80 125 29 29 22 110400 172800 2080 2880 1.3
32017 85 130 29 29 22 112000 179200 1920 2720 1.35
32018 90 140 32 32 24 134400 216000 1760 2560 1.75
32019 95 145 32 32 24 135600 220400 1680 2480 1.8
32020 100 150 32 32 24 137600 224000 1600 2400 1.9
32021 105 160 35 35 26 160800 268000 1520 2240 2.4
32022 110 170 38 38 29 186400 312000 1440 2080 3.05
32024 120 180 38 38 29 193600 332000 1360 1920 3.25
32026 130 200 45 45 34 251200 432000 1280 1760 4.95
32028 140 210 45 45 34 264000 468000 1260 1700 5.25
32030 150 225 48 48 36 295200 524000 1200 1600 6.35
32032 160 240 51 51 38 343200 624000 1040 1440 7.75
