Home > Industrial Equipment & Components > Bearing > Deep Groove Ball Bearing > 61805Z Sealed Bearing, 25x37x7, Bike Bearing

61805Z Sealed Bearing, 25x37x7, Bike Bearing

61805Z Sealed Bearing, 25x37x7, Bike Bearing thumbnail-1
61805Z Sealed Bearing, 25x37x7, Bike Bearing thumbnail-2
61805Z Sealed Bearing, 25x37x7, Bike Bearing thumbnail-3
61805Z Sealed Bearing, 25x37x7, Bike Bearing thumbnail-4
61805Z Sealed Bearing, 25x37x7, Bike Bearing thumbnail-5
61805Z Sealed Bearing, 25x37x7, Bike Bearing thumbnail-6
61805Z Sealed Bearing, 25x37x7, Bike Bearing photo-1
61805Z Sealed Bearing, 25x37x7, Bike Bearing photo-2
61805Z Sealed Bearing, 25x37x7, Bike Bearing photo-3
61805Z Sealed Bearing, 25x37x7, Bike Bearing photo-4
61805Z Sealed Bearing, 25x37x7, Bike Bearing photo-5
61805Z Sealed Bearing, 25x37x7, Bike Bearing photo-6
US$ 2 - 3 MOQ: 1 Piece
Key Specifications
Get Latest Price
Brand Name:
CLUNT or OEM
Place of Origin:
Shandong, China
Model Number:
61805Z
Contact Supplier Request Quote Chat Now
Jinan Kelunte Bearing Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name CLUNT or OEM
Place of Origin Shandong, China
Model Number 61805Z
Number of Row Single Row
Seals Type single shielded
Precision Rating P0 P6 P5 P4 P2
Outside Diameter 0, 37
Bore Size 0, 25

61805Z Sealed Bearing, 25x37x7, Bike Bearing

Company Information

61805Z Sealed Bearing, 25x37x7, Bike Bearing61805Z Sealed Bearing, 25x37x7, Bike Bearing

Product Description



Bearing 61805Z:



Bore Size(mm):25

Outside Diameter(mm):37

Width(mm):7

Weight(kg):0.022

Speed(r/m):16000-20000



1, Deep groove ball bearings are non-separable and require little attention or maintenance in service, capable of operating at high speeds and are widely used radial bearings. The inner and outer ring of single row deep groove ball bearings have a deep groove raceway, the bearings are mainly used to carry radial loads and a part of axial loads in two directions. This kind of bearing can carry much heavy axial loads after the increase of radial clearance, thus, it can take the place of high speed angular contact ball bearings.



2, Deep groove ball bearing have various types in structure, beside open type bearings, shield or seals at both side can also be provided.

Descriptions of 61805Z bearing

6805Z Ball Bearings One Ball Bearing 6805Z, bearing is made from Chrome Steel, bearing has 1 Metal Shields to protect the bearing from dust or any possible contamination, this bearing is self lubricated (bearing is already greased). * Item: 6805Z Ball Bearing * Type: Deep groove ball bearings * Closures: Metal Shields * Quality: Electric Motor Quality * Bearing dimensions: 25mm x 37mm x 7mm * Inner Diameter: 25mm * Outer Diameter: 37mm * Width: 7mm * Quantity: One Bearing * Dynamic load rating Cr: 4,300 N * Static load rating Cor: 2,940 N * Limiting Speed: * Grease Lubrication: 18,000 RPM * Equivalents: 61805-2Z and 61805ZZ Bearings



Features of 61805Z bearing

  • Item: 6805ZZ Ball Bearing
  • Type: Deep groove ball bearings
  • Closures: Metal Shields
  • Quality: Electric Motor Quality
  • Bearing dimensions: 25mm x 37mm x 7mm



 Other deep groove ball bearings

item ID OD Width chamfer LOADING(KN) BALL RUN SPEED WEIGHT
Dynamic Static No. Size Grease Oil KG
Cr Cor mm r/min r/min
6000 10 26 8 0.3 4.55 1.95 7 4.763 29000 34000 0.019
6001 12 28 8 0.3 5.1 2.39 8 4.763 26000 30000 0.021
6002 15 32 9 0.3 5.6 2.84 9 4.763 22000 26000 0.035
6003 17 35 10 0.3 6.8 3.35 10 4.763 20000 24000 0.04
6004 20 42 12 0.6 9.4 5.05 9 6.35 18000 21000 0.068
6005 25 47 12 0.6 10.1 5.85 10 6.35 15000 18000 0.079
6006 30 55 13 1 13.2 8.3 11 7.144 13000 15000 0.113
6007 35 62 14 1 16 10.3 11 7.938 12000 14000 0.149
6008 40 68 15 1 16.8 11.5 12 7.938 10000 12000 0.185
6009 45 75 16 1 21 15.1 12 8.731 9200 11000 0.231
6010 50 80 16 1.1 21.8 16.6 13 8.731 8400 9800 0.256
6200 10 30 9 0.6 5.1 2.39 8 4.763 25000 30000 0.032
6201 12 32 10 0.6 6.1 2.75 7 5.953 22000 26000 0.037
6202 15 35 11 0.6 7.75 3.6 8 5.953 19000 23000 0.045
6203 17 40 12 0.6 9.6 4.6 8 6.747 18000 21000 0.066
6204 20 47 14 1 12.8 6.65 8 7.938 16000 18000 0.106
6205 25 52 15 1 14 7.85 9 7.938 13000 15000 0.128
6206 30 62 16 1 19.5 11.3 9 9.525 11000 13000 0.199
6207 35 72 17 1.1 25.7 15.3 9 11.112 9800 11000 0.288
6208 40 80 18 1.1 29.1 17.8 9 12 8700 10000 0.366
6209 45 85 19 1.1 32.5 20.4 10 12 7800 9200 0.398
6210 50 90 20 1.1 35 23.2 10 12.7 7100 8300 0.454
6300 10 35 11 0.6 8.2 3.5 6 7.144 23000 27000 0.053
6301 12 37 12 1 9.7 4.2 6 7.938 20000 24000 0.06
6302 15 42 13 1 11.4 5.45 7 7.938 17000 21000 0.082
6303 17 47 14 1 13.5 6.55 7 8.731 16000 19000 0.115
6304 20 52 15 1.1 15.9 7.9 7 9.525 14000 17000 0.144
6305 25 62 17 1.1 21.2 10.9 7 11.5 12000 14000 0.232
6306 30 72 19 1.1 26.7 15 8 12 10000 12000 0.36


 61805Z Sealed Bearing, 25x37x7, Bike Bearing61805Z Sealed Bearing, 25x37x7, Bike Bearing61805Z Sealed Bearing, 25x37x7, Bike Bearing61805Z Sealed Bearing, 25x37x7, Bike Bearing61805Z Sealed Bearing, 25x37x7, Bike Bearing61805Z Sealed Bearing, 25x37x7, Bike Bearing


Certifications

61805Z Sealed Bearing, 25x37x7, Bike Bearing61805Z Sealed Bearing, 25x37x7, Bike Bearing61805Z Sealed Bearing, 25x37x7, Bike Bearing61805Z Sealed Bearing, 25x37x7, Bike Bearing

Our Services
We are 100% manufacture. We can supply you technical support.
We have strict quality control processes. We supply high quality bearings with fair price.
We accept small quantity.
We may supply other globle brand bearings and offer buyer labels.
We can manufacture any bearings according to customer's drawings
