2019 High Capacity Food Grade Pregelatinized Corn Cassava Starch Making Machine Automatic Potato Tapioca Modified Machinery

Product Application

modified starch / Pre-gelatinized starch is an effective and economical fluid loss agent in water based drilling fluids, which is a starch derivative. It is not bacterial degradation when at 120°C, environmentally acceptable and non-toxic. Modified Starch can produce a thin, slick, tough filter cake and promotes faster penetration rates with reducer friction. It can be used in all kinds of drilling fluid system. Pre-gelatinized starch is also sometimes "pregelatinized" to make them easier to dissolve during product manufacture. Modified starch is widely used in oil drilling, textile, paper and food industries.

Hot Sale Automatic Potato Tapioca Corn Modified Starch Machine uses cheap natural starch, like corn starch, cassava starch, tapioca starch etc as main materials, through extruding treatment process, to produce multi-functional and high-valuable modified starch, Pre-gelatinization Starch or Denatured Starch. Its Double Screw Extruder is special designed, consists of 6 systems: feeding system, extruding system, cutting system, heating system, conveying system and cooling system, its barrels and screws structure can easily realize the function of changing the properties of the starch. Modified Starch can be used in many fields like Textile, Food, paper making, building material, casting, oil drilling and so on.

1. Raw Materials: natural starch, like corn starch, cassava starch, tapioca starch etc
2. Products: Modified Starch.
3. Capacity: 150 KG/H,200-250 KG/H,400-500 KG/H

4. Flow Chart: Mixing -Extrusion -Baking -Grinding
5. Voltage: Three phases: 380V/50HZ, Single phase: 220V/50HZ, we can make it according to customers' local voltage of different countries.
6. Machines Materials: All the machines are made by food grade stainless steel.
7. Technical Parameters

Main Features

1. The screw is made of alloy (38CrMoAL) by nitriding process, high strength and wear-resting. And it has good self-cleaning ability and does not need to discharge or clean the barrel and screw, when roasting or replacing of materials.
2. It adopts speed-adjusted converter on feeding system, extrusion system and cutting system. Food grade stainless steel twin screw feeding machine guarantees stable materials feeding in the whole food process.
3.The gearbox has automatic lubrication function, with extends gear life.
4. Radiator is increased on driving part for forced cooling effect, and it ensures extruder operate safely.
5. Barrel with water-cooled circulation, it makes extruder can be used not only for corn/rice, also for wheat flour/starch which are raw materials with high viscosity. Through different moisture-extrusion temperature ratio, it can make whole-expanded and half expanded as different type of products.
6. Cutting knife fixed in the die head seat, rotary cutting by V-belt drive.

Twin Screw Extruder

Model :DZ100

Brand: SAIXIN

Screw diameter: 100mm

Twin Screw Extruder

Name: DZ135
Brand: SAIXIN
Screw diameter: 135mm

Twin Screw Extruder

Model: DZ160
Brand: SAIXIN
Screw diameter: 160mm

contract person: lisa xia

  Jinan Saixin Machinery Co.,Ltd is high-tech company with technology,manufacturer and trade,which is the chief member of the China Foodstuff and Packing Machinery association.
With the advanced technology,strict management,and excellent service,we gain the high reputation of customers from domestic and abroad. Meanwhile,we has been awarded lots of honors these years:"Shandong High-tech Company","Jinan High-tech Excellent Company", "Jinan High-tech Star Company" and "Jinan Key Protective Company" etc.Our company is the earliest professional manufacturer of food machinery,which has been committing to the development and research of food technology and equipment more than 10 years.We invented the first generation ,the second generation and the the third generation production technology and equipment of puffed extruder,we are the one of main professional manufacturers of puffed extruder.We won the honor of "China Important New Product" and Shandong Famous trademark,as well as several pants.
Warm attitude,good reputation,excellent quality and perfect service are our faith,SAIXIN is strictly management on product quality,sales and after service,developing and improving products according to customers advices and requirements to make customers' satisfactory.
As for the market demand,we establish food processing equipment department.This food processing equipment is with high-tech to lower the food cost,full automation to save the expenses of labor,and efficient to guarantee the quantity.The machine is stable performance,easily clean,and meet the requirement of food production.
We have,on the basis of domestic market,developed international market and established a sales network throughout the world.Our products are sold very well in domestic market and are also sold to South-east Asia,Eastern Europe,Africa and other countries. Our market share is increasing each year.
Saixin will go all out and make innovations to contribute to the development of our foodstuff industry together with those companies in this line.
