Low Price 4V200 Series 5/2 Way 4V210-08 Double Electric Control Solenoid Valve

Low Price 4V200 Series 5/2 Way 4V210-08 Double Electric Control Solenoid Valve photo-1
US$ 6 - 6 MOQ: 1 Piece
Key Specifications
Get Latest Price
Brand Name:
KLQD
Place of Origin:
Zhejiang, China
Model Number:
4V210-08
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo
Delivery Detail:
Delivery time depends on order quantity.
Brand Name KLQD
Place of Origin Zhejiang, China
Model Number 4V210-08
Application General
Structure Pilot
Standard or Nonstandard Standard
Pressure Medium Pressure
Port Size 1/4''
Temperature of Media Medium Temperature
Product Description

Low Price 4V200 Series 5/2 Way 4V210-08 Double Electric Control Solenoid Valve

4V
2
10
08
B
W
AC220V
Specification
Code
4V:5/2(3) Way
Solenoid Valve
4A:5/2(3) Way
Pneumatic Control Valve
3V:3/2 Way Solenoid Valve
3A:3/2 Way
Pneumatic Control Valve
Series Code
200 Series
10:Single-head Double position
20:Double-head Double-position
30C:Double-head Three-position
Close Type
30E:Double-head Three-position
Exhaust Type
30P:Double-head Three-position
Pressure Type
Port Size
06:1/8''
08:1/4''
Joint Pipe Form and Initial State
Blank:Pipe Connection Type
B:5/2 Way Plate Connection Type
5/3 Way Plate Connection Type
NC:3/2 Way Normal Close Type
NO:3/2 Way Normal Open Type

Wiring Form
Blank:
Standard
Connector
LD:Brown with Lighting
Connector
LD1:White with Lighting
Connector
W:Lead Wire
Type
Standard Voltage
DC12V
DC24V
AC24V
50Hz/60Hz
AC110V
50Hz/60Hz
AC220V
50Hz/60Hz
AC380V
50Hz/60Hz

1.Working medium:40 Micron Filtered Air

2.Working pressure:0.15~0.8MPa

3.Ambient Temperature:5~50℃

4.Insulation&Protection Class:F Class. IP65

5.Highest Action Frequency:5 Cycle /Sac

6.Internal hole adopts special processing technology which has little attrition friction,low star pressure and long service life.

7.Several standard voltage grades are optional.

    Working Voltage:DC12V DC24V AC110V AC220V

Detailed Images
Packing & Delivery
Payment
Production Processed
FAQ

Q1. Is sample order acceptable?
A: Yes.It's ok.

Q2. How to place the order?
A: You can send us email or inquiry at alibaba directly.

Q3. How many days for delivery?
A: We have stock for standard products.

Q4. How to make the payment?
A: We accept BankT/T,Western Union,Paypal,or L/C.

Q5. How Will You Make the Shipment?
A.Sea Shipment by Pallet Packing.
B.Air.
C.Express Service.

Q6. Do you test all your goods before delivery?
A: Yes, we have 100% test before delivery.
