Home > Industrial Equipment & Components > Valve > Ball Valve > BSP CWX-60P DN15 1/2" Dn20 3/4" Two Way 12v Plastic Pvc Motorized Valve for Water

BSP CWX-60P DN15 1/2" Dn20 3/4" Two Way 12v Plastic Pvc Motorized Valve for Water

BSP CWX-60P DN15 1/2" Dn20 3/4" Two Way 12v Plastic Pvc Motorized Valve for Water photo-1
BSP CWX-60P DN15 1/2" Dn20 3/4" Two Way 12v Plastic Pvc Motorized Valve for Water photo-2
BSP CWX-60P DN15 1/2" Dn20 3/4" Two Way 12v Plastic Pvc Motorized Valve for Water photo-3
BSP CWX-60P DN15 1/2" Dn20 3/4" Two Way 12v Plastic Pvc Motorized Valve for Water photo-4
BSP CWX-60P DN15 1/2" Dn20 3/4" Two Way 12v Plastic Pvc Motorized Valve for Water photo-5
US$ 8 - 30 MOQ: 1 Piece
Key Specifications
Get Latest Price
Brand Name:
TF CWX-60p
Place of Origin:
Tianjin, China
Model Number:
CWX-60p motorized valve
Payment & Shipping
Payment Methods:
Port of Shipment:
Tianijn China
Delivery Detail:
Delivery time depends on order quantity.
Brand Name TF CWX-60p
Place of Origin Tianjin, China
Model Number CWX-60p motorized valve
Application General
Structure Ball
Port Size 1/2",3/4",DN15,DN20
Media Water
Product Description



BSP CWX-60P DN15 1/2" dn20 3/4" two way 12v plastic pvc motorized valve for water

BSP CWX-60P DN15 1/2" dn20 3/4" two way 12v plastic pvc motorized valve for water



1,Metal gearbox and metal gear design, low noise, perform reliably
2,Long service life: more than 100000 circles
3,Electric limit and machinery limit design, located accurately, avoid gear run

     continuously.
4,Multi-angle assembling, easy to install
5,Float ball structure, no leakage,especially suitable for heavy pollution conditions.



BSP CWX-60P DN15 1/2" dn20 3/4" two way 12v plastic pvc motorized valve for water



1. IC card smart water meter, heat meter
2. HVAC and fan coil, fire sprinkler, etc.
3. Universities water, automatic control systems, industrial automation and other small devices
4. Environmental protection, water supply and drainage, water treatment
5. Replace the solenoid valve where can not working
6. The water-saving appliances, equipment and other drinking water



BSP CWX-60P DN15 1/2" dn20 3/4" two way 12v plastic pvc motorized valve for water



Product model Rated voltage Working current Output torque Open/close time Control mode
 CWX-60P

DC3-6V

DC12V
AC/DC9-24V
AC220V
AC85-265V

Max100mA

(CR04 except Max150mA)

 Max6NM <8s CR01   CR02 CR02+  CR03 CR03A CR03T CR04  CR05 CR06
Working pressurePowerMedium temperatureSizeIP GardeCustomised
 Max1.0Mpa <5W0-90℃ DN8-32 Two-way DN8-25 Three-way IP65 CR01 CR02 CR02+ CR03 CR03A CR04(with singal feedback)

BSP CWX-60P DN15 1/2" dn20 3/4" two way 12v plastic pvc motorized valve for water



BSP CWX-60P DN15 1/2" dn20 3/4" two way 12v plastic pvc motorized valve for water





Brass ConnectionSizes  H
Both female thread Full-port DN8 846 31
 DN15 15 5738
 DN2020  71 45
 DN2523.5  7249

Both feamle thread

Reduce-port

 DN1046 31
DN15106638
DN20157247
DN32 25  8660

Vertical

Three-way

DN15126349
DN20156653
Female-male thread DN15156338
DN20156638
DN25158144
DN32207650
 Both male thread DN1515 68  38
CPVCBoth female threadDN15156047
DN20207251
SS304/316 Both female thread DN8  8 46 31
DN10  46 30.5
DN15  15 5538
DN20  1563 39
DN20 2071 45
DN25  20 75 47
DN25  25 72 49
Horizontal Three-way (Brass) Sizes d L1 L2 H
 DN8 6 52.6 39 24.5
 DN10 12 72 55 39
 DN20 15 86 63.5 44
 DN25 15 97 68.5 43.5



BSP CWX-60P DN15 1/2" dn20 3/4" two way 12v plastic pvc motorized valve for water

BSP CWX-60P DN15 1/2" dn20 3/4" two way 12v plastic pvc motorized valve for water

BSP CWX-60P DN15 1/2" dn20 3/4" two way 12v plastic pvc motorized valve for water







Company Information

BSP CWX-60P DN15 1/2" dn20 3/4" two way 12v plastic pvc motorized valve for water

Tianjin Tianfei High-Tech Valve Co., Ltd. is a professional manufacturer of electric valve and manual valve, is a founding company of Tianjin Valve industry.Tianfei has a professional

R & D team,has won many letters of petent and the recognition of the Tianjin municipal government departments.“CWXis our brand and our company has passed the

ISO9001,CE,RoHS,NSF61 certificate and so on,the products have exported to many countries and regions worldwide.

Our company motto is novative, simplified, high-valued, As having accumulated rich experiences and resources during more than 10 years developing, we are confident in providing you satisfied products and service in the cooperation. Tianfei pays attention to the quality of the products,use CWX valve is your correct choice.

BSP CWX-60P DN15 1/2" dn20 3/4" two way 12v plastic pvc motorized valve for water

Packaging & Shipping

BSP CWX-60P DN15 1/2" dn20 3/4" two way 12v plastic pvc motorized valve for water

FAQ

BSP CWX-60P DN15 1/2" dn20 3/4" two way 12v plastic pvc motorized valve for water

1. Are you manufacturer or trading company?
We are manufacturer, we had been produced electric valve for more than 10 years. So we have advantage in price. We also could do OEM.



2. What's the payment method?
T/T,Paypal,Western Union, Moneygram,Aliexpress, L/C ect.



3.What's your Minimum Order Quantity (MOQ)?
Our MOQ is 1piece.

4. What about the delivery time?
Sample need about 3 working days, large order delivery time will according to your quantity.



5..Would you have a discount if l have a large order?
A; Yes we could offer different discount according to your order quantity.



6.Where is the factory located?
Tianjin city and welcome to visit our factory.
