1000V 1500V High Voltage Solar Wiring PV Connector
Product drawing of PV Connector:
Technical data of PV Connector:
| Insulation material | PPO |
| Rated current | Max.50A |
| Rated voltage | 1000 /1500 V DC |
| Test voltage | 8KV(50HZ,1 min) |
| Contact resistance | < 0.5mΩ |
| Contact material | Copper,Tinned |
| Degree of protection | IP2X/IP68 |
| Safety class | II |
| Overvoltage category/Pollution | CATIII/2 |
| Flame class | UL94-10 |
| Inserlation force | Max.50N |
| Withdrawal force | Min.50N |
| Ambient temperature range | -40 ~ +85 ºC |
Pls click here for more detail and price from Slocable.
Product picture of PV Connector:
Product advantage of PV Connector:
1. Simple on-site processing
2. Mating safety provided by keyed housings
3. Multiple pluging and unpluging cycles
4. High current carrying capacity
5. TUV and CE approved
6. Quick, Parallel Connection of PV Modules
More products of Slocable:
Pls click here for more detail and price from Slocable.
Our case
Q1: What is your company's Main Products ? You are the Manufacturer or the trader ?
Solar Cables, Solar Connectors, PV Fuse Holder,Circuit breakers and other solar relative products.
We're the Manufacturer with more than 12 years experience.
Q2: How can I get the Quotation of the products ?
Send your Message to us by E-mail / TradeManager,We'll reply you within 1 hour in the Working Time.
Q3: How does your company do regarding Quality Control?
1)All raw material we selected the high quality one.
2)Professional & Skilful workers care every details in handling the producing.
3)Quality Control Department specially responsible for quality checking in each process.
Q4: Do you provide OEM Project Service?
OEM & ODM order is warmly welcome and we have fully successful experience in OEM projects.
What's more, our R&D team will give you the professional suggestions.
Q5: How Could I get the Sample?
We are honored to offer you samples,Samples is free provided,but need pay the courier freight.
If you have a courier account, you can send your courier to collect samples.
Q6: How long is the Delivery time?
1) For Sample: 1-3 Days ;
2) For small Orders: 3-10 Days;
3) For mass Orders: 10-18 Days.
If any question, feel free to contact me.
Pls click here for more detail and price from Slocable.
