Home > Products > Solar PV connector > Slocable Discount Price 14awg 12awg 10awg CN40 CM-01 IP68 IP67 Waterproof Capacity
Slocable Discount Price 14awg 12awg 10awg CN40 CM-01 IP68 IP67 Waterproof Capacity
- T/T Credit Card
You May Like
-
High Voltage IP67 3 to 1 Solar Plug Socket Branch PV Connector for Solar Panels
-
TUV CE Certified IP68 Waterproof 1500V Solar mc Wire Connectors for 2.5mm 4mm 6mm Cable
-
IP68 Waterproof Wire Connector Electrical Connectors for Solar Photovoltaic System
-
Slocable Waterproof 40A 2 Pin Solar Connector PV Plastic DC Cable Connectors
-
High Current Carrying DC Anti-water Solar Ground Connector
-
25 Years Working Life 14AWG 12AWG 10AWG 8AWG CN40 PV DC Power Connector
Product Details
| Brand Name | Slocable | Place of Origin | Guangdong, China | |
| Model Number | CN40-CM-01 PV Connector | Type | MCX | |
Product Description
Slocable Discount Price 14AWG 12AWG 10AWG C40-CM-01 IP68 IP67 Waterproof Capacity from Slocable
Detail Information and Advantages of IP68 Solar Connector
-
- Simple on-site processing
- Mating safety provided by keyed housings
- Multiple plugging and unplugging cycles
- Accomodates PV cables with different insulation diameters
- High current carrying capacity
- CE and TUV Certificates
- IP68 Waterproof Capacity
(check the previous video of Slocable Solar working under the water.)
Technical Data of Thick Pure Copper Terminal Solar
| Technical Data of Standard Terminal Solar Connector | |||
| Rated Current | 50A | Degree of Protection | IP2*/IP68 |
| Rated Voltage | 1000V/1500V DC | Flame Class | UL94-V0 |
| Test Voltage | 6000V (50Hz,1min) | Safety Class | II |
| Overvoltage Category | CATIII | Suitable Cable | OD 4.5-8.5mm (2.5-6.0mm²) |
| Contact Resistance | <0.5mΩ | Connecting System | Crimp Connection |
Insertion Force / Withdrawal Force | ≤50N/≥50N | Temperature Range | -40℃~+85℃ |
| Contact Material | Copper, Tin Plated | Insulation Material | PPO |
Our terminals are standard (thickness 0.4), meeting the TUV standard.
Pictures of Black Plastic Solar with Standard Terminals
Click the following Picture to get more Slocable products:
Shipment of Waterproof Solar Connector:
1.We ship to world-wide;
3.Item shipped from China mainland using airmail by EMS, UPS, DHL, Fedex, TNT or Hong kong Post Office, reach most of the countries within 4 to 10 business days;
4.Delivery time: 3-20 working days on payment received (except holiday), most we have some stock to support for emergency;
5.After we ship the item, we will email you the shipping information, as well as the tracking number;
6.If it happens to be any duties, taxes and any other fees charged by the courier company and your respective country, the buyers are duty to pay.
|
IF any inquiry, please do not hesitate to contact me!
