Common Rail Diagnostic Calibrating Tools XBD-3000A Test Bench Specially Designed For Diesel Common Rail Injectors and Pumps
- Qingdao
- T/T Credit Card
You May Like
-
Trustworthy China Supplier Common Rail Diesel Injector Test Bench/fuel Injection Pressure Tester
-
CR708 CR3000A Common Rail Tester Common Rail Diesel Fuel Injector Pump Test Bench From Taian Manufacturer
-
XBD- CRSII Common Rail Injector Tester Multifunctional Diesel Fuel Injector Pump Tester
-
220V Pneumatic Common Rail Injector Tester
-
XBD-CRS815 Common Rail System Test Bench
-
Highly Professional Diesel Pump and Injector Test Bench XBD-CR100
Product Details
| Brand Name | Xinbaodi | Place of Origin | Shandong, China | |
| Model Number | XBD-CR3000A | Power | Electronic | |
| Usage | Auto Testing Machine |
Product Description
XBD-3000A Diesel Common Rail Test Bench
XBD-CR3000A High Pressure Fuel Injection Pump and Injector Test Bench is specially designed by us for testing common rail fuel injector and common rail pump, having advanced functions and accurate measurements. It is controlled by industrial computer and has windows operation system. It automatically measures and displays fuel quantity, checks, and stores and revises the tested data and generates database which can be freely updated. It adopts 0-1800bar rail force caused by original BOSCH high pressure common rail fuel injection pump, and automatically regulates the rail pressure. It can test the fuel injector and pump produced by BOSCH SIEMENS, DELPHI, DENSO, having reliable functions, accurate measurements, organic-glass protection door, and easy operation.

Common Rail Test Bench Features:
1, Timely controlled by industrial computer, windows operating system
2, Fuel quantity measured by sensor and displayed on 19 inch LCD monitor.
3, Database can be checked and stored.
4, Breakdown can be remote diagnosed.
5, Adopt 0-1800bar rail force caused by original BOSCH high pressure common rail fuel injection pump.
6, Compulsory refrigerated system control the fuel temperature.
7, Timely measure the rail force, and have protection for high pressure.
8, Fuel injector pulse width of drive signal and frequency can be regulated.
9, Can freely set times and duration of injections of the fuel injector.
10, Short- circle protection
11, Accurate measurement, simple operation, energy saving and low noise.
Common rail test bench function:
I Test common rail fuel injector
1, Test Brands: BOSCH,DENSO,DELPHI,SIEMENS;
2, Test 1-6 branches common rail injector
3, Test estimated injection of common rail fuel injector.
4, Test maximum fuel quantity
5, Test launching fuel quantity
6, Test returned fuel quantity
II Test common rail fuel pump
1, Test Brands: BOSCH,DENSO,DELPHI,SIEMENS;
2, Test leak tightness of high pressure common rail diesel fuel injector.
3, Test inner pressure of common rail pump
4, Test scale solenoid valve of common rail pump
5, Test function of fuel output pump
6, Timely test rail force
7, Test fuel flow of common rail pump
8, Database can be checked and stored.
Data of common rail test bench
Main motor speed | 0-4000 r/min, can be adjustable |
Motor power | 5.5kw |
Fuel Injector open voltage | Control range: 12v, 80v, 150v Control accuracy: phase adjustment |
Injector opening frequency control | 0-1000HZ Control accuracy: 1HZ
|
Fuel injector hold time | Control range: 0-65535us |
Delivery oil count | Control times: 0-1000times Control accuracy: 1 time |
Fuel pressure control | 0-2000 bar Control accuracy: 1bar |
Electronic power | 3 phase 380V / 3 phase 220V optional |
Package
The package is wooden case or plywood case, if you need, we can also pack the products according to your demands.
Contact
TAIAN XINBAODI EXPERIMENTAL EQUIPMENT CO., LTD
Add : NO. 1#-2-402,WEST OF DONGYUE STREET, TAIAN CITY, SHANDONG, CHINA
Mob:0086-13562896072
WeChat: 0086-13562896072
WhatsApp: 0086-13562896072
Skype: testbench201010
E-mail: testbenchina*
Website: https://xinbaodi.en.china.cn
FAQ
Q: How many days to produce this test bench?
A: It need 5-20 days to produce the test bench.
Q:How can I pay for it?
A:We support TT payment, West Union, and L/C etc.
Q:How to sign an order?
A:We can sign an order offline or online on Ali.
Q:How long of warranty?
A:12 months
Q:Do you have some repairing tools?
A:Yes, we have many kinds of repairing tools for common rail injector and pump.
