JTY model pedal hydraulic press machine
General introduction
l gateway steel frame structure
l adopts the hydraulic ram with manual and foot-operated functions
l applied in dismounting, molding, aligning in the vehicle repairing
l It is safe and easy to operate
Technical parameter:
Model no | JTY |
Material | U-steel |
Painting | High quality paint |
Color | Blue |
Max working press | 200KN(20T) |
Max working height | 860mm |
Max working width | 700mm |
Stroke | 250mm |
Oil cylinder pressure | 45Mpa |
Total height of the press | 1700mm |
Total width of the press | 1050mm |
Accessories: | |
V-shape iron plate,support tools, etc. | |
Others you may want to know: | |
MOQ | 1set |
Warranty period | 12 months |
Payment term | T/T 50% in advance, the balance should be paid before delivery (negotiable) |
Delivery time | 20 days after receiving downpayment |
HS code | 84639000.90 |
Similar other press machines:
Click for more details:
https://haolida.en.china.cn/productgrouplist-209530477/Manual_Pedal_Electric_Hydraulic_Press_Series.html?spm=a2700.icbuShop.prup15aafb.17.55bc2eebC8CqCi
Why Choose us:
1. 32 years’ design,development and produce experience
2. Professional R&D team
3. Strict QC
4. A good pre-sale and after-sale service
5. Can design and make according to customer’s requests
