Test Bench for Heavy Duty Truck Generator Starter Motor

Test Bench for Heavy Duty Truck Generator Starter Motor thumbnail-1
Test Bench for Heavy Duty Truck Generator Starter Motor thumbnail-2
Test Bench for Heavy Duty Truck Generator Starter Motor thumbnail-3
Test Bench for Heavy Duty Truck Generator Starter Motor thumbnail-4
Test Bench for Heavy Duty Truck Generator Starter Motor photo-1
Test Bench for Heavy Duty Truck Generator Starter Motor photo-2
Test Bench for Heavy Duty Truck Generator Starter Motor photo-3
Test Bench for Heavy Duty Truck Generator Starter Motor photo-4
US$ 1 - 1 MOQ: 1 Set
Key Specifications
Get Latest Price
Brand Name:
Haolida
Place of Origin:
Shandong, China
Model Number:
FQZ-2A
Contact Supplier Request Quote Chat Now
Qingdao Haolida Automotive Equipment Manufacturing Co., Ltd
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao/Shanghai/Guangzhou
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name Haolida
Place of Origin Shandong, China
Model Number FQZ-2A
Power Electronic
Usage Auto Testing Machine



                      FQZ-2A Model Test Bench for Heavy Duty Truck Generator Starter Motor



General introduction

1.It can be used to test Alternators and Starters of various vehicles (Car, Truck, Bus, Tractor, Excavator, etc);

2.Test Alternator (Generator): 5.5KW, 0-200A, 12V or 24V, 10000RPM

Test item: Speed, Voltage, Current (Load or no-load)

3.Test Starter: 15KW, 0-2000A, 0-200N.M, 12V or 24V or 48V

Test item: Torque, Voltage, Current (Load or no-load)



Advantages:

1.It uses variable frequency speed regulation

2.It displays result by digital instrument, the test result is accurate and can be read directly.

3.It is easy to learn and operate.

4.It is with fuse protection.

5.It is with indicator lamp following each step and warn you the problems.

6.It does not need battery to test alternator, it can excite voltage itself.

7.It needs external battery to test starter.

8.High quality speed sensor.

9.It possesses high control sensitivity and strong controllability.

10.It can be matched with PLC computer to operate, display, save & print test results and curves.

 Test Bench for Heavy Duty Truck Generator Starter MotorTest Bench for Heavy Duty Truck Generator Starter Motor

Technical parameter:



Model no

FQZ-2A

Language

English/Spanish, etc

Material

Metal plate

Painting

Powder painting, durable and beautiful

Color

Blue

Voltage

380V 50 Hz 3P (other voltage acceptable)

Motor power

7.5KW

Motor speed

0-3600Rpm

Frequency converter power

11KW

Alternator testing:

Maximum power

7.5KW

Maximum current

200A

Maximum voltage

80V

External battery

No

Excitation voltage

12V/24V

Speed range

No load:0-12000Rpmad;  Load:0-10000Rpm

Load mode

Electronic module (advance)

Motor drive style

Belt connect

Clamp style

Mounting clamp, fasten or loosen with button control, easy to mount or remove

Starter testing:

Maximum Power

15KW

Maximum current

2000A

Maximum torque

200N.m

Test solenoid excitation voltage

12V/24V

Need external battery

12V/24V/48V

Accessories:

Accessory wires, belt, blank plates for starters, fuses, etc.

Others you may want to know:

MOQ

1set

Warranty period

12 months

Payment term

T/T 50% in advance, the balance should be paid before delivery  (negotiable)

Delivery time

30 days after receiving downpayment

HS code

90312000.90

Packing sizes

1870*1020*1660mm=3.17CBM

 Customer onsite checking: Test Bench for Heavy Duty Truck Generator Starter Motor

Packing:

Test Bench for Heavy Duty Truck Generator Starter Motor

    Other kind of alternator and starter test benches for reference:





Test Bench for Heavy Duty Truck Generator Starter Motor



Why Choose us:

1.32 years’ design,development and produce experience

2.Professional R&D team

3.Strict QC

4.A good pre-sale and after-sale service

5.Can design and make according to customer’s requests



Company images, honors and contact:

Test Bench for Heavy Duty Truck Generator Starter Motor

Test Bench for Heavy Duty Truck Generator Starter MotorTest Bench for Heavy Duty Truck Generator Starter MotorTest Bench for Heavy Duty Truck Generator Starter MotorTest Bench for Heavy Duty Truck Generator Starter Motor
