Shunt Test Unit -STU for VD4 EL
US$ 50 - 2,500
MOQ: 10 Pieces
Key Specifications
Get Latest Price
Brand Name:
ABB
Place of Origin:
China
Model Number:
STU
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen/Hongkong
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Auxiliary Contacts -BB0 for VD4 ELUS$ 50 - 2,500MOQ: 10 Pieces -
Contact for Signalling Closing Spring Charged/discharged -BS2 for VD4 ELUS$ 50 - 2,500MOQ: 10 Pieces
-
Locking Magnet on the Operating Mechanism -RL1 for VD4 ELUS$ 50 - 2,500MOQ: 10 Pieces
-
Electronic Time Delay Device -KT for VD4 ELUS$ 50 - 2,500MOQ: 10 Pieces
-
Undervoltage Release -MU for VD4 ELUS$ 50 - 2,500MOQ: 10 Pieces
Brand Name
ABB
Place of Origin
China
Model Number
STU
Shunt Test Unit -STU for VD4 EL
STU Shunt Test Unit
Due to the particular construction of these releases, checking the functionality of the shunt closing (-MC) and opening (-MO1, -MO2) releases is not possible with dedicated relays (e.g. TCS Test Control Supervision, CCC Control Coil Continuity) or with the REF control and protection unit. The only device able to carry out a check of the functionality is the STU device. Please contact us if you want to carry out this control with devices other than STU.
This device can be combined with the shunt opening release (-MO1; -MO2) or with the shunt closing release (-MC) to check functionality and continuity.
The control/monitoring Shunt Test Unit allows the continuity of releases with a rated operating voltage between 24 V and 250 V (AC and DC) to be checked, as well as the functionality of the electronic circuit of the release.
Checking continuity is carried out cyclically with an interval of 20 seconds between one test and the next.
Charateristics
| Suit for | items |
| VD4 EL | Shunt opening release(-MO1) 110V DC/AC |
| VD4 EL | Shunt opening release(-MO1) 220V DC/AC |
| VD4 EL | Additional shunt opening release(-MO2) 110V DC/AC |
| VD4 EL | Additional shunt opening release(-MO2) 220V DC/AC |
| VD4 EL | Shunt closing release(-MC) 110V DC/AC |
| VD4 EL | Shunt closing release(-MC) 220V DC/AC |
| VD4 EL | Motor operator (-MS) 110V DC/AC 220W |
| VD4 EL | Motor operator (-MS) 220V DC/AC 220W |
| VD4 EL | Undervoltage release (-MU) 110V DC/AC |
| VD4 EL | Undervoltage release (-MU) 220V DC/AC |
| VD4 EL | Electronic time delay device(-KT) 110V DC/AC |
| VD4 EL | Electronic time delay device(-KT) 220V DC/AC |
| VD4 EL | Locking magnet on the operating mechanism (-RL1) 110V DC/AC |
| VD4 EL | Locking magnet on the operating mechanism (-RL1) 220V DC/AC |
| VD4 EL | Contact for signalling closing spring charged/discharged (-BS2) |
| VD4 EL | Auxiliary contacts (-BB1) 3NO+2NC |
| VD4 EL | Auxiliary contacts (-BB2 -BB3) 2NO+3NC |
| VD4 EL | Shunt Test Unit (STU) 25-250V DC/AC |
Packing & Shipping:
Payment methods:
Samples order: Paypal or Western Union
Main order: T/T
Delivery time:
Small orders: 5-7 working days
Bulk orders:15-30 working days
Our Company information:
Wuhan WOFOTO Electric CO.,LTD
belongs to CHINA WOFOTO GROUP CO.,LIMITED
-Wuhan WOFOTO Electric Co.,Ltd
Main Sales: Generator circuit breaker, SF6 circuit breaker, SF6 Disconnect Switches, Vacuum Circuit Breaker, Vacuum Contactor, SF6-Ring Main Unit, Automatic Transfer Switch, Relay protection devices, Distribution transformer, Air circuit breaker.
Brands:Schneider, ABB, SIEMENS, GE
Website:
WhatsApp:+86 13797009877
skype:wofotocn
WOFOTO is willing to work with friends worldwide together and win-win
Let WOFOTO embrace the World!
