PIX distribution system components
PIX distribution system consists of several functional units interconnected to form.
Power distribution system through a separate bus to achieve between the functional units
Power connection.
The ground bus of each functional unit is connected to the main connection of the substation
To the ground, in order to achieve all the metal structure of the equipotential bonding
To the ground.
The low-voltage trough is located between the low pressure.
The low voltage cable enters from the top or bottom of each functional unit.

Functional unit description
The functional unit includes the main circuit and the secondary circuit device, which
Jointly provide protection. Each functional unit consists of the following
Component:
- cabinet
- Protection, monitoring and control systems
- Parts can be extracted

Main feature

- Switchgear made of aluminum-zinc plate production, modular design, assembled flexible and convenient,

high strength

- equipped with Schneider Electric's advanced HVX vacuum circuit breaker, the operating mechanism

for the spring operation
Institutions, operating agencies optional electric operation
- Can be equipped with Schneider Electric's advanced CVX vacuum contact hand wagon composed of

F-C cabinet
- Available parts (handcart) for the center, the ground flatness requirements are low, can be extracted

from the parts swap
- All switch operation can be performed while the panel is closed, and the operator is more secure
- perfect mechanical interlock, and simple and reliable
- Depending on the need, select the circuit breaker compartment from the front of the cabinet (front wiring)

or from the rear of the switchgear Line mode) for high-voltage cable connection
- Separate upwards pressure relief device is provided in the circuit breaker room, busbar room and

cable compartment
- Reliable wall installation
- High resistance to internal arc fault
- Intelligent monitoring and protection functions can be realized

Parameter

Packing & Shipping

Payment methods:

Samples order: Paypal or Western Union

Main order: T/T

Delivery time:

Small orders: 5-7 working days

Bulk orders:  15-30 working days
