50Hz 60Hz YCT Magnetic Speed Variable Motor Electromagnetic AC Motor
US$ 801 - 1,145
MOQ: 1 Set
Key Specifications
Get Latest Price
Brand Name:
YUTONG
Place of Origin:
Henan, China
Model Number:
YCT250-4B
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao/Tianjin/Shanghai/Ningbo/As request
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Induction Motor Sales Magnetic Motor SaleUS$ 690 - 2,250MOQ: 4 Sets -
Yutong YCT Series Magnetic Motor AC Constant Torque Stepless Speed Adjustable for Paint LinesUS$ 230 - 2,966MOQ: 2 Sets
-
Magnetic Motor Electric GeneratorUS$ 250 - 1,740MOQ: 3 Sets
-
Magnetic Motor Free EnergyUS$ 220 - 3,200MOQ: 2 Sets
-
3 Phase Induction Motor Magnetic Energy FreeUS$ 160 - 3,200MOQ: 2 Sets
Brand Name
YUTONG
Place of Origin
Henan, China
Model Number
YCT250-4B
HENAN YUTONG ELECTRIC MOTOR SHARES COMPANY
ADDRESS: NO. 76, ZHONGYANG RD, XINXIANG ECO. DEV. ZONE, HENAN PROVINCE, CHINA
CONTACT: TEL 0086-373-5066677 FAX 0086-373-5066776 MOBILE: 0086-15603819991
Skype:jocelynjin1003 WhatsApp:+86-15603819991
Wechat: 1215516364 QQ NO.: 1215516364
Company Profile
- Henan Yutong Electric Motor Shares Company is the largest processional manufacturer of general electric motor and vibration motor in Henan Province, North China.
- Yutong motor has advanced equipments including high-precision NC machine tool and vacuum impregnation.
- Yutong motor has motor core production line, motor assembling production line and digital automatic test lines, which can complete the whole process from spare parts processing to motor assembling test.
- Our products are sold to all over the world including Indonesia, Chile, Thailand, Russia, South Africa, Spain, India, Vietnam, the United Arab Emirates, Sweden and other countries.
Product Descriptions
- A type of stepless speed-adjustable motor with AC constant torque
- It consists of electromagnetic slipping clutch of pulling motor (three-phase induction motor), velocity-testing generator and controller.
- With wide regulating range, no non-control area, large starting torque, strong and frequent starting without impact on electric network, stable speed and high accuracy.
- Can be widely used in textile, chemical, metallurgical, building materials industry, paper-making and synthetic resin.
Technical Specifications
- Output Range: 0.55KW~450KW
- Voltage: 415V/380V/660V/as required
- Frequency: 50Hz/60Hz/as required
- No. of Poles: 2, 4, 6, 8, 10, etc
- Speed: 450rpm~3000rpm
- Torque: 3.6Nm~564Nm
- Protection class: IP21
- Cooling method: IC01
- Duty type: S1
- Insulation class: B
- Connection: Y/D
- Mounting styles: B3/B5/B35/V1, etc.
- Altitude: less than 1000m
Product Model |
Power of the Motor (kW) |
Rated Torque (N·m) |
Speed Adjustable Range (r/min) |
|
YCT112-4A |
0.55 |
3.6 |
1250-125 |
|
YCT132 -4A |
1.1 |
7.1 |
1250-125 |
|
YCT132 -4B |
1.5 |
9.7 |
1250-125 |
|
YCT160-4A |
2.2 |
14.1 |
1250-125 |
|
YCT160-4B |
3 |
19.2 |
1250-125 |
|
YCT180-4A |
4 |
25.2 |
1250-125 |
|
YCT200-4A |
5.5 |
36.1 |
1250-125 |
|
YCT225-4A |
11 |
69 |
1250-125 |
|
YCT225-4B |
15 |
94 |
1250-125 |
|
YCT250 -4A |
18.5 |
110 |
1320-132 |
|
YCT280-4A |
30 |
189 |
1320-132 |
|
YCT315-4A |
37 |
232 |
1320-132 |
|
YCT315-4B |
45 |
282 |
1320-132 |
|
YCT355-4A |
55 |
344 |
1340-440 |
|
YCT355-4C |
90 |
564 |
1340-600 |
