Brand Name TAILIKE, ZD
Place of Origin Zhejiang, China
Certification CCC, CE, ROHS, UL

brush auto sliding door motor gate

Motor performance parameters:

 Mode

Voltage

Power

No-load Parameters

Load Parameters

Allowable Torque Gear Motor

Motor Weight



 V



W

Speed

r/min

Current

A

Speed

 r/min

Torque mN.m

Current A

  GK8.5

  mN.m

  GK13

  mN.m



   Kg

ZDMJ-1

 24

 60

2300

0.4Max

1800

318

4.0

1840

2650

1.2

ZDMJ-2

 90

 60

2300

0.3Max

1800

318

1.1

1840

2650

1.0

ZDMJ-3

 24

 60

3000

0.6Max

2500

229

4.0

1320

2000

1.2

ZDMJ-4

 24

 60

3000

0.6Max

2500

229

4.0

GX12.5/1950

1.0



Main data:

1.Basic specification:DC24V,60W,2500RPM S1,B CLASS,IP20,IP40

2.Rated torque of bare motor:318mN.m,229mNm

3.No-load noise of whole motor:<50dB,L=50cm

4.VE:AC66V,1S,5mA

5.Insulation resistance:>20MΩ 500V,>20MΩ 500V

6.Life:2500H,4000H

7.Ambient request:RoHs

8.Gear Ratio:8.5,12.5,13



Product characters:

This product  adopted PMDC brush motor as the main part of rotor.It can be matched with computer system of control.It can realise self-supervise through matching with computer,and you can set the best working model.

Such asspeed ,impetus,resistant power and so on.It has characters of low noise,small volume,light,long lift and wide use.Meanwhile,it can meet the customers'request of update.

                   brush auto sliding door motor gate

                         brush auto sliding door motor gate

                        brush auto sliding door motor gate
