MY-T035 Durable Medical Full Automatic Washer Disinfector For Surgical Instruments

 MY-T035 Durable Medical Full Automatic Washer Disinfector For Surgical Instruments

Equipment type Class II b
Total volume 545L
Usable volume 500L
Power supply 3phase ~380V 50Hz
Work type short time loading, continuous running
Maximum input power ≤30000VA
Rated power of water heater 28.5KW
Rated power of drying heater 10KW
Ambient temp. 5°C~40°C
Ambient humidity 30%~95% (no condensation)
Ambient pressure 700hPa~1060hPa
Water quality requirements purified water: 4~7°d
steamed water: 0°d
1°d =10mg/L CaO=17.80mg/L CaCO3
Notice: To avoid white spots on instruments after processing, if purified water is not qualified, please use steamed water or distilled water instead
water consumption 40L/step
Dimension of water outlet DN 20
Dimension of aeration port DN 32
Gas vent Φ90mm
Water source G 3/4 exterior screw thread
Water source pressure 0.2~0.5MPa
Water flow ≥25L/min
Installation Landing installation
Standard cleaning cycle Pending on the environment, operation model, type of instruments and loaded volume.
Enzyme agent consumption in standard cycle 200ml/cycle adjustable
Antirust agent (gloss oil) consumption in standard cleaning cycle 200ml/cycle adjustable
Water consumption in standard cleaning cycle 200ml/cycle
Cleaning temperature 30~93°C adjustable
Drying temperature 60~120°C adjustable
Shape dimension 1260x1005x1920
Package dimension 1415x1170x2140
Chamber shape rectangular
Chamber dimension 730x730x940
Washing shelf dimension 663x752x618
Layer of washing rack five layers
Loading capacity of each layer 20kg/layer
Net weight Approx. 680kg
Gross weight Approx. 720kg
Chamber material 304 stainless steel
Cover material 304 stainless steel
Scheduled maintenance cycle half a year
Screen 7 inch, TFT true color, touch screen
Printer micro stylus printer
Dimension of trolley 796x682x920
Dimension of instruments tray 498x230x50/226x226x50
