 Vehicle-mounted Hydraulic Water Well Drilling Rig Made in China

Shandong Beijun Heavy Industry Co., Ltd.
 Vehicle-mounted Hydraulic Water Well Drilling Rig Made in China thumbnail-1
 Vehicle-mounted Hydraulic Water Well Drilling Rig Made in China thumbnail-2
 Vehicle-mounted Hydraulic Water Well Drilling Rig Made in China thumbnail-3
 Vehicle-mounted Hydraulic Water Well Drilling Rig Made in China thumbnail-4
 Vehicle-mounted Hydraulic Water Well Drilling Rig Made in China thumbnail-5
 Vehicle-mounted Hydraulic Water Well Drilling Rig Made in China photo-1
 Vehicle-mounted Hydraulic Water Well Drilling Rig Made in China photo-2
 Vehicle-mounted Hydraulic Water Well Drilling Rig Made in China photo-3
 Vehicle-mounted Hydraulic Water Well Drilling Rig Made in China photo-4
 Vehicle-mounted Hydraulic Water Well Drilling Rig Made in China photo-5
US$ 26899 - 27000 MOQ: 1 Set
Key Specifications
Get Latest Price
Brand Name:
BJ
Place of Origin:
China
Model Number:
XYC-200
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
QINGDAO
Delivery Detail:
10 days

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name BJ
Place of Origin China
Model Number XYC-200
Type Core Drilling Rig
After-sales Service Provided No overseas service provided
Warranty 1 year
Weight 1150kg
Dimension(L*W*H) 1110*725*965
Power Type Diesel
Voltage 220v
Usage Water Well
Condition New
Power(W) 14.7kw


Products Description
1. Characteristics of XYC-200 vehicle-mounted hydraulic water well drilling rig
XYC-200 is a multi-function vehicle-mounted hydraulic water well drilling rig.Automobile chassis chassis, transmission system and rig winch, mud pump and other important accessories installed in the chassis. the layout is reasonable, compact, and easy to operate.
It is equipped with high pressure,big flow BW160 mud pump,which can ensure drilling depth and diameter.
the rig has shifting device, it can move on the vehicle and is convenient to operate while drilling.
the hydraulic folding mast is safe and convenient to transport
2.Applications of XYC-200 vehicle-mounted hydraulic water well drilling rig
road and high-rise building foundation exploration
all kinds of concrete structure inspection holes
river embankments
subgrade grouting holes
drilling and direct grouting
civil water well
ground temperature central air conditioners.
3. Parameters of XYC-200 vehicle-mounted hydraulic water well drilling rig
XYC-200 vehicle-mounted hydraulic water well drilling rig
Drilling depth(m)
30-200
Drilling diameter(mm)
300-75
Drilling angel(mm)
90-75
Spindle rotating speed(r/min)
64/128/287/557
Spindle stroke(mm)
450
Main hoisting capacity (single line)(Kg)
1600
Main hoisting line capacity (m)
35
Hoisting speed(r/s)
17/35/75/151
Wireline diameter(mm)
12.5
Mast height(mm)
7000
Mast effective height(mm)
6500
Kelly/active pipe(mm)
59*53
Drill rod(mm)
42/50/60
Drill rig weight(kg)
1150

Power unit
Model
ZS1115 diesel engine
Rated power
14.7kw/2200rpm



BW-160 mud pump
Rated flow(l/min)
160
Rated pressure(mpa)
1.3
Driving power(kw)
5.15
Main machine weight (kg)
190
Dimension(mm)
1110*725*965
Chassis
light truck(Pictures of vehicle-mounted drilling rigs for reference only)
