MAYA Medical Portable Anesthesia Machine Anesthesia Equipment With Low Price

Feature:

l  CE approved portable anesthesia machine

l  Compact light-weight and portable, could be transported by pull-rod case, put on table and assembly on the trolley.

l  Jackson or Bains Absorber is available

l  Specifically designed to accomodate low flow

l  Selectatec-bar and quick change vaporizer mounting device

l  Professional airtight breathing circuit design, provide the stable gas anesthesia, save anesthesia gas consumption, to ensure a clean operating room and laboratory environment.

l  External and reusable soda lime canister, easily watch and replace soda lime.

l  With Oxygen flush function to ensure that clinical anesthesia demand and Oxgyen supply demand.

l  With APL pressure reducing valve to prevent pressure to hurt the animal, ensure the animal safety .

l  Wastewater discharge system

l  Visible inspiration and expiration valve

l  Could upgrade to Oxygen&N2O or Oxygen&Air flow meter freely

l  Module rack with polyester medical material with superior spray technology, high strength and light weight.

l  With transport case, convenient to take and transport

l  Easy to disassemble and assemble all the components, convenient for clean and maintenance.

Specification:

Application: Adult and pediatric( 3kg over)

Ventilation mode: Closed, half-closed, half-open

Tidal volume( Manual Mode): 10~2000ml

Gas pressure: 0.25~0.65Mpa

Flow meter: Oxygen two tube: one tube:0.1~1,one tube:1~10L/M

APL valve: 0.5~6.0Kpa

OXYGEN Flush: 25~75L/min

I:E: As the doctor operation

BPM: As the doctor operation

Monitoring: Airway pressure, respiratory mode.

Three gauges: One for Oxygen source pressure

One for oxygen working pressure

One for airway pressure

Vaporizer
With the latest innovative design of delivery system, vaporizers deliver accurate concentration under varying conditions of variable flow rate, pressure, temperature and so on.
Stably deliver agent, automatic temperature-compensating, deliver accurate agent
Sophisticated delivery system,Stable, prompt, accurate
Various kinds of mounting types.

Safety lock device to prevent the anesthetic gas volatile accidentally.

The big view window is convenient to observe drug usage levels.

Specification
Concentration range:
Enflurane 0.2 to 5%
Isoflurane 0.2 to 5%
Halothane 0.2 to 5%
Sevoflurane 0.2 to 8%

Flow range:0.2 to 15L/min
0.2 to 10L/min(normal usage)for concentrations>5 vol%
Filling volume for agent:
About 340ml with dry wick
About 300 ml with moist wick

Mounting type:
selectatec compatible
draeger plug in
cagemount(ISO 23mm tapers)


Net Weight: 26kg

Gross Weight: 30kg

Size:86 X51 X 38CM

1. For all your inquires about us or our products, we will reply you in detail within 24 hours.
2. We own professional team with professional attitude to recommend products and services, introducing the products for you.
3. Our products have various type and function, We will recommend to you that according to your requirements ; The products have one year free warranty, after which they can still be provided after-sales service.
4. We offer OEM services, And we can print your own logo on the products.
5. We have well-experienced engineers, who can help you better use our products.

Your satisfaction is our duty! It will be our great honor to serve you. We do hope we can offer you more help in medical field and build the long term business relationship with you.

Q: How to buy your products ?

A: We have some products in stock , you can take away the products after you arrange the payment ; If we don’t have the products in stock you want, we will start  production once getting the payment.

Q: What’s the warranty for the products ?

A: The free warranty is one year from the date of commissioning qualified.

Q: Can we visit your factory ?

A: Of course, welcome to visit our factory if you come to China.

Q: How long is the validity of quotation ?

A: Generally, our price is valid within one month from the date of quotation. The price will be adjusted appropriately as the price fluctuation of raw material in the market.

Q: What’s the production date after we confirm the order ?

A: This depends on the quantity. Normally, for the mass production, we need about one week to finish the production.

Please contact us for more detail information.

Delivery detail:
1.We ship the products by air or sea for you.
2.Our products with standard export packing.
3.No matter what delivery way, all depending on your actual requirements.
