Description of the  High Speed Refrigerated Centrifuge:

As an advanced intelligent device,  Intelligent High-Speed Refrigerated Centrifuge

is widely applicable in a variety of fields such as biochemistry, medical treatment and public health,

food safety, life science, forestry, animal husbandry, blood banks, blood stations, biological products

and pharmaceutical products. It is the ideal equipment for separation, precipitation, concentration and

preparation of samples and a high-tech product that can compare favorably with import ones and be

exported in large quantities.

Specifications of the High Speed Refrigerated Centrifuge:

Using a brushless motor with high torque and variable frequency which is controlled by an SCM of Microchip’s dsPIC30F Series and driven by a

special driver module of FAIRCHILD’s FSBB30CH Series to ensure the circuit’s reliability.

The design of the whole machine is in line with the ergonomics, with streamlining sculpt. With a complete steel structure and a stainless steel

centrifuge cavity, it is safer, better looking and more efficient.

With multiple protection measures such as super speed, over heat and imbalance as well as a special combination of shock absorbers to keep the

motor running smoothly. With triple protective layers of steel bushings to achieve secure and reliable operation as well as personnel and equipment

safety.

Rotors at rest will be in standby and cool down.

With TFT true-color LCD wide screen touch monitor featured by intelligent control, easy and convenient operation, a touch panel and a

simultaneous indication of both the set parameters and operation ones.

With a dedicated key indicating the centrifugal force which has the inching function for momentary centrifugation.

With a motor gate lock mute mechanical & electrical integration.

Able to provide more than 100 kinds of operating modes for the user to programme and use freely.

10 levels for speed-up/speed-down control.

Maximum rotatiton speed: 30000r/min, Maximum centrifugal force: 62400×g.Model 3H30RI 3H26RI 3H

Maximum capacity 4×100ml Swing Bucket Rotor

Maximum rotate speed(r/min): 30000

Maximum centrifugal force(×g): 62400

Standard rotor: 4×1.5/2.0 ml(Titanium alloy)

Rotate speed precision ±50r/min

Refrigeration system Import fluoride-free compressor and control valve

Temperature control range -20℃~+40℃

Temperature control precision ±1℃

Operation programmes 100

Control and drive systems AV Variable Frequency Motor, Microcomputer control, Direct drive

Total power 1.5kw

Timer range 0-99h59min

Noise ≤65dB

Rotor identification Automatic rotor identification function

Weight 75kg

Dimension (L×W×H) 710×630×350mm

Picture of High Speed Refrigerated Centrifuge:

    MY-B002B                                                        MY-B010B

          MY-B064                                                       MY-B041A

1. For all your inquires about us, we will reply you in  detail within  24 hours.

2. We own professional team with professional attitude to recommend products and services  for you.

3. The  products  have one year free warranty,  after which they  can still be provided after-sales service.

4. We offer OEM services. And we can print your own logo on the product.

5. We have well-experienced engineers, who can help you better use our products.

Your satisfaction is our duty! It will be our great honor to serve you. We do hope we can offer you more help in medical field and build the long term business relationship with you.

Q: How to buy your products ?

A: We have some products in stock , you can take away the products after you arrange the payment ; If we don’t have the products in stock you want, we will start  production once getting the payment.

Q: What’s the warranty for the products ?

A: The free warranty is one year from the date of commissioning qualified.

Q: Can we visit your factory ?

A: Of course, welcome to visit our factory if you come to China.

Q: How long is the validity of quotation ?

A: Generally, our price is valid within one month from the date of quotation. The price will be adjusted appropriately as the price fluctuation of raw material in the market.

Q: What’s the production date after we confirm the order ?

A: This depends on the quantity. Normally, for the mass production, we need about one week to finish the production.

Please contact us for more detail information.
