Concrete Screed Paver Leveling Machine in South Africa
Product Application
Mainly used for road paving leveling. Suitable for paving, leveled, vibrated, pulp, leveling of high grade highway, airport runway, rural roads and other projects. Double motor design, responsible for walking in front of the motor, responsible for leveling vibration at the back of the motor. The steel pipe is divided into seam and seamless steel tubes, and the steel pipe diameter can be divided into 219mm and 165mm.
SPECIFICATIONS FOR CONCRETE PAVER LAYING MACHINE | ||
Commonly paving width(m) | 4 | |
Max paving width(m) | 13 | |
Max paving thickness(mm) | 320 | |
Paving speed(m/min) | 0-18 | |
Walk speed(km/h) | 0-2.6 | |
Commonly working efficiency(t/h) | 700 | |
Engine power(KW) | 28 | |
Grade ability | 25% | |
Planeness | 1.5mm/3m | |
Cross slope error | ±0.02 | |




Main Features
1. The characteristics of seamless steel tube with thick steel pipe are not welded, not collapse, not deformation.
2. Operation lever control, one can operate, simple and convenient, save labor.
3. The motor adopts the national standard pure copper core motor.
4. High vibration frequency of the eccentric shaft, the chamber effect is good.








We have an independent factory, with 12 years of independent r & d production experience
Strict quality control system, each product will exceed 12 hours of quality inspection, to ensure product quality
We have a professional after sales team, 24 hours online for you to solve any product question
Support products to customize, can be tailored according to your requirements
Fast shipment, safe packing, ensure the goods are in good condition and timely delivery to you


1.Q: How can I make the payment?
Sample orders 100% T/T in advance. If mass order, T/T L/C are acceptable.
2. Q: Can I order mix order?
Yes.
3. Q: How long of the warranty period?
1year
4. Q: How can i believe you and your factory?
A:Since it is not the little thing to purchase machine, you can come to China to visit us for an inspect, and we will welcome you enthusiasm. so we can establish good cooperation with each other.
Reply you in 24 hours, if you are urgent, we can reply you soonest.
