1.Application:
The touch-screen electronic Brinell hardness test is mainly used to determine the hardness of cast iron, steel, non-ferrous metals and soft alloys, in addition, it can also be used to determine the hardness of some non-metallic materials, such as hard plastics, bakelite and so on. The hardness meter removes the loading weight and adopts the electronic automatic loading system. It has ten levels of test force, wider testing range and higher precision. Applicable to factories, workshops, laboratories, colleges and universities and scientific research institutions.
The test is mainly used to determine the hardness of cast iron, steel, non-ferrous metals and soft alloys.
The load weight is removed and the electronic automatic loading system is used.
With ten levels of test force, the range of test is wider and the precision is higher
2.Technical Parameter:
Brinell scale: HBW2.5/62.5,HBW2.5/187.5,HBW5/125,HBW5/750,HBW10/100,
HBW10/1500,HBW10/3000,HBW10/250,HBW10/500,HBW10/1000
Test power: 62.5kgf (612.9N), 100kgf (980.7N), 125kgf (1226N), 187.5kgf (18)
39N),250kgf(2452N),500kgf(4903N),750kgf(7355N),1000kgf(9807N),1500kgf(14710N),3000kgf(29420N)
Maximum height of specimen: 280mm
Minimum unit of measurement: 0.005mm
Load retention time: 5~ 60s
Hardness range: 8~650HBW
Total magnification: 20X
Executive standards: EN, ISO 6507, EN ISO 6506, ASTM E-384, ASTM E-10-08, ASTM E-384 GB/T231.2,JJG150
Indenter center to body distance: 150mm
Hardness reading: check table
Power supply: AC220±5% / 50~60Hz
Shape dimension (mm): 550*236*750mm
Host weight: 123kg
3.Features:
*Rugged, rigid, accurate, reliable, durable, high test efficiency;
*Automatic closed-loop force sensor control system, 10 Test force selection, 14 trials ruler;
*Overload, over-bit auto-protection, electronic afterburner, no weight;
*Automate the testing process, and no one was operator error;
*Large LCD display, menu smart tips, easy to operate;
* Flexible and convenient operation function with the English conversion;
*Optional CCD image processing system;
*Accuracy according GB/T231.2, ISO6506-2 and American ASTM E10 standards.
1.Shipping & delivery: It depends on your requirement. We offer as many shipping options as possible, we have cooperated with some transpotation companies and shipping companies. If you need, we can transport products to our country port or even shipping to your country port.
2. Machine' Packaging: Simulation Aninmatronic Costom Triceratops are covered with air bubble firm before put them into the wood en case, which not only has good shock absorption, impact resistance, heat sealing and also has theadvantages of nontoxic, odorless, moisture corrosion, good transparency ect.
