YAW-300D Automatic constant pressure stress testing machine and pressure gauge
We also have 300KN hydraulic compression testing machine for choice
Introduction:
This machine adopt computer auto control, with constant test speed, constant stress, test force keeping and other control mode. The computer realize test data and test curve’display, save,manage function, can print test report. With special fixtures, can test other material compression.
Features and Function:
1. This testing machine adopt AC servo system drive the AC servo motor,by precision reduction gears drives the ball screw,with high test accuracy,low noise.
2. Without pressure oil leakage and proportional valve blocking, low noise, more reliable.
3. Window control and dealing software, design more reasonable.
can arbitrarily set pressure value, pressure time, auto calculate test result.
4. Advanced auto control function, can do single or batch test.
5. Auto stop,after sample broken.
6. With over load protection.
Main Specs:
Max compression test force |
300kN |
Max flexual test force |
NONE |
Test force range |
2%~100%FS |
Test force accuracy |
≤±1% |
Load speed |
0.1~9.9KN/S |
Displacement indicate error |
±1% |
Displacement resolution |
0.01mm |
Displacement speed adjust |
0.01~40mm/min |
Control and deal mode |
Computer constant control and auto dealing |
Effective test width |
300mm |
Space between upper and lower |
280mm (optional) |
Effective compression space |
50mm |
Compression plate size |
140mm |
Machine size |
630×457×1410mm |
Power supply |
220V,50Hz,1500W |
YES-1000 Digital Display Compression Testing Machine YES-2000D Digital Display Compression Testing Machine
We supply full range services:
Pre-sale, we provide comprehensive advisory services, tailored for different industries to meet customers’ special needs.
After-sale, we could supply door to door installation and training services according to customer requirements .
During the use process, if there is any problem, your could reach our technical engineers in time by e-mail, remote video, telephone and other possible ways.
The machine parts is free of charge during the warranty period ,and machines lifetime maintenance.
