NDT-6000 6000J PLC Controls And Touch Screen Computer Control Drop Hammer Impact Testing Machine
US$ 3,500 - 4,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Brand Name:
HST
Place of Origin:
Shandong, China
Model Number:
NDT-6000
Payment & Shipping
Payment Methods:
Port of Shipment:
QINGDAO
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
JB-C Series 300J 450J 500J Semi-automatic Charpy Impact Testing MachineUS$ 2,500 - 3,000MOQ: 1 Set -
JBW-Z Series PLC Control Automatic Feeding And Position Device Impact Testing MachineUS$ 4,500 - 5,000MOQ: 1 Set
-
JBS-300B 300J 150J Touchscreen Digital Display Charpy V-notch Impact Testing MachineUS$ 3,800 - 4,000MOQ: 1 Set
-
300J 150J Pendulum Impact Testing Machine Manual Charpy Impact TesterUS$ 1,300 - 1,500MOQ: 1 Set
-
300J 500J JBS-B Series Touchscreen Digital Display Charpy Impact Testing MachineUS$ 3,500 - 4,000MOQ: 1 Set
Brand Name
HST
Place of Origin
Shandong, China
Model Number
NDT-6000
Power
Electronic
DWTT 100000J Computer Control Drop Weight Impact Testing Machine
Phone/whatsapp:+86-15866781190 Skype:hstbetty009
Product Description
1. Application:
This type of machine is specially for conducting drop-weight test to determine nil-ductility transition temperature of ferritic steels.
2.Standard:
GB/T6803-86,ASTM E208-95A
3.Main Technical Parameters:
Model |
NDT-3000 |
NDT-4000 |
NDT-6000 |
Maximum Energy(J) |
3000 |
4000 |
6000 |
Minimum Energy(J) |
300 |
500 |
750 |
Maximum Tup Mass(kg) |
90 |
120 |
204 |
Tup Mass Accuracy |
±1% |
||
Drop Height(mm) |
750~3400 |
750~3000 |
|
Velocity Of Drop(m/s) |
3.8~7.6 |
||
Hammer Lifting Speed(m/min) |
3 |
||
Height Resolution |
0.1 |
||
Height Accuracy(mm) |
≤±10 |
||
Hardness Of Tup Nose |
HRC58-62 |
||
Radius Of Tup Nose(mm) |
R25.4±2.5 |
||
