Best selling plastics packaging materials high low temperature mechanical tensile testing machine
It is widely used in controlling the quality; Rubber & Plastics; metallurgical iron and steel; manufacturing machinery; electronic equipment; automobile production; textile fiber; wire and cable; packaging materials and foodstuffs; instrumentation; medical equipment; civilian nuclear energy; civil aviation; colleges and universities; research Laboratory; inspection arbitration, technical supervision departments; building materials, ceramic; Petroleum &Chemical; other industries.
Model |
WDW-5 |
WDW-10 |
WDW-20 |
WDW-30 |
WDW-50 |
WDW-100 |
Max. Load |
5kN 500kgf 1120lbf |
10kN 1000kgf 2240lbf |
20kN 2000kgf 4480lbf |
30kN 3000kgf 6720lbf |
50kN 5000kgf 11200lbf |
100kN 10000kgf 22400lbf |
Load accuracy |
≤±1% |
|||||
Load range |
2%-100% of full scale |
|||||
Load resolution |
1/200000 of full scale |
|||||
Disp. resolution |
0.01mm |
|||||
Test speed |
0.05-500mm/min |
0.05-300mm/min |
||||
Tensile space |
750mm|30in |
650mm|25.6in |
650mm|25.6in |
|||
Comp. space |
750mm|30in |
650mm|25.6in |
650mm|25.6in |
|||
Test width |
375mm |
400mm |
420mm |
|||
Temperature range |
-40°C~350°C |
|||||
Thermostat specifications |
High precision temperature control meter , multilevel PID adjust, interval 1°C, accuracy: 0.5°C |
|||||
Temperature fluctuation |
±1°C |
|||||
Temperature gradient |
Better than 3°C |
|||||
Heating up time |
Room temperature to 300°C, less than 50 minutes |
|||||
|
Uniform temperature zone length |
More than 150mm |
|||||
Size of oven body |
Hearth: depth 650mm×width 240mm×height400mm Overall size:1000mm×390mm×600mm |
|||||
Material |
Stainless steel inner shell, long durability, good anti-corrosion performance |
|||||
Structure |
Large observation window, easy operation, with guide rail |
|||||
High temperature box power |
2kW/AC380V/50Hz |
|||||
Dimension |
730×430×1700mm |
755×480×1780mm |
825×600×1950mm |
|||
Power supply |
220V, 1ph, 0.5kW |
220V, 1ph, 0.75kW |
220V, 1ph, 1kW |
|||
Weight (kg) |
250kg|550lb |
280kg|616lb |
350kg|770lb |
|||
