WDS-5 5KN Digital Electronic Universal Tensile Strength Laboratory Testing Machine
1. Application:
WDS-10 Electronic Universal Material Tensile Testing Machine are designed and manufactured
according to ASTM, ISO, DIN, GB and other international standards. Applicable for wide range of material for tensile, compression, bending, shearing and low cycle test. It is for metal, rubber, plastic, spring, textile, and components testing. Widely used in corresponding industries, research and development, test institutes and training centers etc.
2. Features:
2.1 Automatic stop: After the sample broken, automatic stop.
2. 2 Display: Real-time display testing force, displacement, testing speed, peak value, testing status on one LCD.
2.3 Automatic return: automatic return to initial position when testing finished.
2.4. Limiting protection: Program control and Mechanical limiting protection.
2.5 High accuracy photoelectric encoder to measure the displacement
2.6 High accuracy load cell to measure the test load
2.7 Ball screw no backlash to guarantee the low noise and high driving efficiency
2.8 High accuracy servo motor to control test speed
2.9 Adopt reliable, durable and high accuracy digital electronic device
2.10 Can built-in multiple load sensor control channel
2.11 Thousands of test fixture can be used according to different test request
2.12 Micro printer optional, can realize testing data print
3. Standard:
ASTM E4, ISO7500-1. EN10002-2, BS1610, DIN51221
4. Main Specifications:
Model |
WDS-5 |
WDS-10 |
WDS-20 |
WDS-30 |
WDS-50 |
WDS-100 |
|
Max. Load |
5kN 500kgf 1120lbf |
10kN 1000kgf 2240lbf |
20kN 2000kgf 4480lbf |
30kN 3000kgf 6720lbf |
50kN 5000kgf 11200lbf |
100kN 10000kgf 22400lbf |
|
Load accuracy |
≤±1% |
||||||
Load range |
2%-100% of full scale |
||||||
Disp. resolution |
0.01mm |
||||||
Test speed |
0.05-500mm/min |
0.05-300mm/min |
|||||
Tensile space |
750mm|30in |
650mm|25.6in |
650mm|25.6in |
||||
Comp. space |
750mm|30in |
650mm|25.6in |
650mm|25.6in |
||||
test width |
375mm |
400mm |
420mm |
||||
Dimension |
730×430×1700mm |
755×480×1780mm |
825×600×1950mm |
||||
Power supply |
220V, 1ph, 0.5kW |
220V, 1ph, 0.75kW |
220V, 1ph, 1kW |
||||
Weight (kg) |
250kg|550lb |
280kg|616lb |
350kg|770lb |
||||
