Help CenterPLF90 2 Stage Servo and Stepper 90mm Reduction Planetary Speed Reducer
Related Products
-
Hongjun Second Stage Planetary Gear Box 190 PLX Gear Ratio 16:1 For 7.5kw Delta Servo MotorUS$ 400 - 590MOQ: 1 Piece -
Small Differential Gear Box High Precision PLE 60 3:1Gear Ratio Speed Reducer For Cutting MachineUS$ 77 - 79MOQ: 1 Pack
-
Customized Planetary Gear Box For Mitsubishi HC-UFS43K Single Stage 5:1 Speed ReducerUS$ 233 - 235MOQ: 1 Pack
-
Helical Hollow Shaft PLH 90 Planetary Gear Box CNC Machine Stepper Motor Speed ReductionUS$ 197 - 200MOQ: 1 Pack
-
High Torque Second Stage Round Flange PLE 40-32k Washing Machine Servo Speed Reducer Gear BoxUS$ 96 - 98MOQ: 1 Pack
Life time lubracation planet gear wheel epicyclic gear box for robot
Leave an email, we will send the detailed datasheet to you (catalogue)
Bearings are imported from Japan's NSK and Germany FAG. Experts understand that good bearing is the key point for reducer's using life.
Input: perfect dynamic balance design, minimize vibration of the device. No cast parts!
Planetary Gearbox for Stepper Motor & Servo Motor:
1) Series: PLE, PLF, PLS, WPL, WPLF
2) Gearbox outline dimension: 40, 57, 60, 70, 80, 86, 90, 110, 115, 120, 130, 142, 160, 190mm
3) Reduction ratio:
1 Stage: 3:1, 4:1, 5:1, 8:1, 10:1
2 Stage: 9:1, 12:1, 16:1, 15:1, 20:1, 25:1, 32:1, 40:1, 64:1, 100:1
3 Stage: 60:1, 80:1, 100:1, 120:1, 160:1, 200:1, 256:1, 320:1, 512:1, 1000:1
4) Lubrication: Lifetime lubrication
5) Output type: Round and Square
6) Input speed: 3000- 8000rpm
7) Life: 30, 000 hours
8) Backiash: Stage 1: <3 (arcmin)
Stage 2: <6 (arcmin)
Stage 3: <8 (arcmin)
9) Operating temperature: -25C to +90C
Our New invent heavy-duty double support structure, carrying capacity & overload capacity has been doubled.
It's easy to install and same size with the mainstream of Taiwan, could directly replace PHT/VGM high-end planetary reducer.
-----------------------------------------------------------------------------------------------------------------------------------------------------
This spur planetary gearbox is used for servo motor and related device which need to redce speed or enlarge torque! Our spur planetary gearboxes external diameter from 40 to 190, gear ratio from 3 to 1000! It has high precision and are widely used with servo motor such like Panasonnic, Mitsubishi, Omran, Teco...
HOINGJUN Planetary Gearbox Application:
High precision (backlash 3-7 arc minutes), maintenance-free, lightweight design, small size, compact structure, easy install and cost-effective.
Packing Method:
1: MOQ: 1 pcs minimum order
2: Packing: 1 pcs per box or according to your requirements. (Carton / Wooden / Customized)
Shipping:
* We support TNT, DHL, UPS, FedEX, EMS and ourown Shipping Forwarder.
* 3 days by AIR & 30-45 days by SEA. (Europe and North America)
As one of the leading manufacturer for precision planetary gearbox and AC/DC Motor, Hongjun Science and Technology Co., Ltd. works in this field for more than 15 years! We have the biggest market share in domestic China market.
