Leadshine NEMA17 Closed-Loop Stepper Motor 42CME02 and CL42
Step angle: 1.8°
Frame number: 42
Holding torque: 0.2-0.8N.M
Built-in 1000 line incremental photoelectric encoder
High torque
Low fever
High stationarity
High consistency
Leadshine closed-loop stepper motor and driver product adopts the latest motor-specific DSP chip and closed-loop control technology to completely overcome the lost-step problem of open-loop stepping motor, which can significantly improve high-speed performance and acceleration and deceleration performance, and effectively reduce motor heating and reduce motor. vibration.
1, General specifications
Step angle | 1.8° |
Step angle accuracy | ±0.09° (no load, full step) |
Temperature rise | MAX 85K |
Use environment | Temperature: -10~+50°C; Humidity: 85% max |
Insulation grade | B |
Insulation resistance | MIN 100 MΩ,500 V DC |
Withstand voltage | 500 VAC,1 min |
Radial runout | 0.025 mm MAX (load 5N) |
Axial runout | 0.075 mm MAX (load 10N) |
Radial maximum load | 50N (10mm from the flange surface) |
Axial maximum load | Motor weight |
2.Technical specifications
Length mm | model | Torque | Rated current | Resistance/phase | Inductance / phase | Rotor inertia |
N.m | A | Ω | mH | g.cm2 | ||
56 | 42CME02 | 0.2 | 1.5 | 1.4 | 2.67 | 1000 |
62 | 42CME04 | 0.4 | 1.5 | 2.3 | 2.95 | 1400 |
70 | 42CME06 | 0.6 | 2.5 | 0.9 | 4.0 | 2500 |
| 83 | 42CME08 | 0.8 | 2.5 | 1.0 | 4.25 | 2700 |
3.Dimension
Suitable for all kinds of motion control automation equipment and instruments, such as: electronic processing and testing, semiconductor packaging, laser cutting and welding, laser phototypesetting, packaging machinery, engraving machine, marking machine, cutting machine, garment plotter, CNC machine tools, automation Assembly equipment and so on. Is the user expect low noise, high-speed performance and cost-effective competition in the field of choice
HONGJUNST was founded in 2009, is a high-tech enterprise engaged in industrial automation and control product development, production and selling ,sale-after service .
We are committed to R & D and produces about 100 varieties of servo motor and drivers, stepper motor and drivers, precision planetary reducer, five series of products with powerful software, excellent quality performance for many years to maintain the forefront of industry production and sales, selling at home and abroad market. At present, the company has developed into one of the leading manufacturers of China motion control industry
.
