0.6/1KV Cu/xlpe/swa/pvc 4x630mm2 Steel Wire Armoured Cable

FOB Price

US$ 0.1 - 10 / Meter

100 Meters(Min. Order)

Port Qingdao/Tianjin/Ningbo/Shanghai/Guangzhou
Payment TermsT/T Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	Hua dong cable		Place of Origin	Hebei, China
Model Number	YJV YJV22 YJV32

Product Description

0.6/1kV Low Voltage Power Cable

Cu conductor XLPE insulated PVC sheated steel wire armored power cable not only have excellent electric, mechanical properties, but also have powerful resistance against chemical corrosion, heataging and environmental stress. Their structures are simple. The permissible maximum operating temperature is 90'C. It is convenient for using, and they can be laid with no restriction of different elevation.

Rate
Voltage(kv)

Sectional
Area(mm 2 )

No.of Core

1st class

0.6/1

1.8/3

3.6/6

6/10

8.7/15

12/20

18/30

21/35

2nd class

1/1

3/3

6/6

8.7/10

12/15

18/20

26/35

1 Core

1.5-800

25-800

25-1200

35-1200

50-1200

2 Core

1.5-185

25-185

3 Core

1.5-400

25-400

35-400

50-400

4 Core

2.5-400

25-400

5 Core

2.5-400

25-400

Type		Name	Main Application
Cu Core	Al Core	Name	Main Application
YJV YJY	YJLV YJLV	XLPE insulated,PVC or PE Sheathed Power Cable	For laying indoor,tunnel,channel and undergroud,Unable to bear external mechanical force,but bear the traction force during laid
YJV22 YJV22	YJLV22 YJV22	XLPE Insulated,Steel Tape Armoured,PVC or PE Sheathed Power Cable	For laying indoor,tunnel,channel and undergroud Able to bear external mechanical force,but unable to bear large pulling force
YJV32 YJV32	YJLV32 YJLV32	XLPE Insulated,Fine Steel Wire Armoured,PVC or PE Sheathed Power Cable	For laying in shaft with large difference of level.Able to bear external machanical force and maderate pulling force
YJV42 YJV42	YJLV42 YJLV42	XLPE Insulated,Thick Steel Wire Armoured,PVC or PE Sheathed Power Cable	Able to bear positive pressure and pulling force

Note:"ZR-"Include ABC three kinds of flame retardent cables,which are spectively indicated in "ZRA-" or "ZRB-" "ZRC-".For example:"ZRB-YJV","ZRA-YJV22".

Main Technical Quota
1.DC resistance:conductor resistance of finished cable at 20’C per kilometer is not more than the following values.

Nominal Section Area(mm 2 )	1.5 2.5 4 6 10 16 25 35 50 70 95 120 150 185 240 300 400 500 630 800
Copper Core	12.1 7.41 4.61 3.08 1.83 1.15 0.727 0.524 0.387 0.268 0.193 0.153 0.124 0.0991 0.0754 0.0601 0.0470 0.0366 0.0283 0.0221
Aluminum Core	18.1 12.1 7.41 4.61 3.08 1.91 1.20 0.868 0.641 0.443 0.320 0.253 0.206 0.164 0.125 0.100 0.778 0.0605 0.0469 0.0367

2.Voltage Test and Partial Discharge Test

Rate
Voltage Uo(kv)

Item

0.6/1

1.8/3

3.6/6

6/6
6/10

8.7/10
8.7/15

12/20

18/20
18/30

21/35

26/35

Voltage

Test Voltage

3.5

6.5

12.5

30.5

73.5

Test Time

Partial Discharge Test

Test Voltage

6.2

10.4

15.1

20.8

31.1

36.3

Discharge Capacity
