HY200 micro Articulated wheel loader with digger
- 100 Set / Sets per Month
- Qingdao Tianjin Shanghai Ningbo
- T/T Credit Card
You May Like
Product Details
| Brand Name | HYSOON | Place of Origin | Shandong, China | |
| Type | Mini Loader | Certification | CE | |
| After-sales Service Provided | Engineers available to service machinery overseas | Warranty | 1 year | |
| Condition | New | Dimension(Long * Breadth * High) | 2424mm*970mm*2020mm | |
| Moving Type | Wheel Loader | Rated Load | 260kg |
Product Description
Articulated wheel loader, micro digger HY200
1. HY200
HY200 is a versatile mini loader micro digger, articulated steering chassis, 260kg load capacity, all imported hydraulic parts, elegant design, high working performance. Widely used in garden, manufacturing, recycling, roads, buildings, construction, farms and so on. High performance earth moving machine. Standard configuration is with a standard bucket. Multifunctional attachments for optional.
2. Main Specification:
| |
1)Size | |
Dimension | 2430mm* 1080mm* 2045mm |
Length | 2430mm |
Width | 1080mm |
Height | 2045mm |
Bucket Width | 1150mm |
Max Pin Height | 1755mm |
Max Dumping Height | 1295mm |
Max Dumping Distance | 430mm |
Total Length without Bucket | 2015mm |
Turn Radius forward Turning | 2030mm |
2)Engine | |
Rated Power (KW) | 17.15KW(23HP) |
Type | Gasoline |
3)Hydraulic System | |
Pressure | 17Mpa |
Operating Load | 260kg |
Bucket Capacity | 0.15m³ |
Travel Speed | 0-8km/h |
Weight | 900kg |
Fuel tank capacity | 27.45L |
Hydraulic oil tank capacity | 21L |
Max traction | 5KN |
Max Lifting force | 4.6KN |
4)Configuration | |
Engine | 23hp U.S Briggs & Stratton engine |
Pump, Valves, hydraulic system | All Imported Italy brands. |
Tires | With Lawn tires, 20*10.00-10P324P/TL |
Optional Configuration | Electric type |
| |
3. Features | |
• Articulated Steering Chassis, hydrostatic transmission • Two pedals operating way, driving safety and easily. • Ergonomically designed, operation comfortably and safety. • A loader can for many purposes. Quick hitch system, you can change different attachments for different jobs quickly and easily. | |
4. Optional Attachments | |
| |
LCL, steel frame & Plywood packing.
1* 20' Container: 5 sets of HY200 Micro diggers.
1* 40'' Container: 10 sets of HY200 Micro diggers.
Certifications: CE, GOST,ISO9001,SGS, Design Patent,Utility Model Patent.
1). We are professional top Manufacturer of Mini Loaders with attachments in China. 2). Independent of The Design Team, 15 Technical Patents. Accept Your Customization.
4). Responsible, in Good Faith. To Guarantee Delivery. Do Security by Alibaba Onetouch.
2. Our Warranty?
1). Warranty: 1 Year. Offer You Accessories for Free in 1 Year Period.
2). Engine Warranty: 3 Years. International Warranty.
3). Provide Technical Support for Life.
3. Do We have Distributors?
Yes. In South Korea. And we are widely recruit Distributors Around the World.
4.Can We Support OEM?
Yes, we can.
