Mini tractor with front end loader and backhoe
1. HY200
HY200 is a utility mini tractor with front end loader and backhoe for sale, articulated steering chassis, 260kg load capacity, all imported hydraulic parts, elegant design, high working performance. Widely used in garden, manufacturing, recycling, roads, buildings, construction, farms and so on. High performance earth moving machine. Standard configuration is with a standard bucket. Multifunctional attachments for optional.
2. Main Specification:
| |
1)Size | |
Dimension |
2430mm* 1080mm* 2045mm |
Length |
2430mm |
Width |
1080mm |
Height |
2045mm |
Bucket Width |
1150mm |
Max Pin Height |
1755mm |
Max Dumping Height |
1295mm |
Max Dumping Distance |
430mm |
Total Length without Bucket |
2015mm |
Turn Radius forward Turning |
2030mm |
2)Engine | |
Rated Power (KW) |
17.15KW(23HP) |
Type |
Gasoline |
3)Hydraulic System | |
Pressure |
17Mpa |
Operating Load |
260kg |
Bucket Capacity |
0.15m³ |
Travel Speed |
0-8km/h |
Weight |
900kg |
Fuel tank capacity |
27.45L |
Hydraulic oil tank capacity |
21L |
Max traction |
5KN |
Max Lifting force |
4.6KN |
4)Configuration | |
Engine |
23hp U.S Briggs & Stratton engine |
Pump, Valves, hydraulic system |
All Imported Italy brands. |
Tires |
With Lawn tires, 20*10.00-10P324P/TL |
Optional Configuration |
Electric type |
| |
3. Features | |
|
• Articulated Steering Chassis, hydrostatic transmission • Two pedals operating way, driving safety and easily. • Ergonomically designed, operation comfortably and safety. • A loader can for many purposes. Quick hitch system, you can change different attachments for the mini tractor loader quickly and easily, then different jobs. | |
4. Optional Attachments | |
|
| |
LCL, steel frame & Plywood packing.
1* 20' Container: 5 sets of HY200 mini tractor with front end loader and backhoe.
1* 40'' Container: 10 sets of HY200 mini tractor with front end loader and backhoe.
Certifications: CE, GOST,ISO9001,SGS, Design Patent,Utility Model Patent.
1). We are professional top Manufacturer of Mini tractor loader in China. 2). Independent of The Design Team, 15 Technical Patents. Accept Your Customization.
4). Responsible, in Good Faith. To Guarantee Delivery. Do Security by Alibaba Onetouch.
2. Our Warranty?
1). Warranty: 1 Year. Offer You Accessories for Free in 1 Year Period.
2). Engine Warranty: 3 Years. International Warranty.
3). Provide Technical Support for Life.
3. Do We have Distributors?
Yes. In South Korea. And we are widely recruit Distributors Around the World.
4.Can We Support OEM?
Yes, we can.
Contact:
Magic Ye
Taian Hysoon Machinery Co.,Ltd
Skype: magicye123
Wechat: cnmagicye
qq: 2904281767
Trademanager: cn1510438888
Mob&Whatsapp: 0086 18660826265
